Analog High Definition Cameras and DVRs
1080p HD Video over Existing Coax

AHD (Analog High Definition) Technology—
High Definition Video Transmission over Coax Cable
Analog High Definition (AHD) signal uses existing coaxial cable infrastructure while providing an unparalleled image quality up to 1640ft (500m) using RG59 cables. AHD technology leverages the robustness of analog signal infrastructure for a seamless upgrade to the details and clarity of 1080p high definition resolution.

View All Products Product Selector
Camera Features:
  • Analog High Definition (AHD) HD over Coax Technology
  • STAR-Light™ Super Low Light Technology
  • Wide Dynamic Range (WDR)
  • Fixed, Varifocal and Auto Focus P-Iris Lens Options
  • True Day/Night Mechanical IR Cut Filter
  • CleanView™Hydrophobic Dome Coating Repels Water, Dust and Grease(V6 Models Only)
  • Smart IR™ with Intelligent Camera Sync. 100~150flt Range
  • Smart DNR™ 3D Digital Noise Reduction
  • Highlight Masking Exposure (HME)
  • Auto Sensing 24VAC/12VDC with Line Lock
  • Secondary Video-BNC Output (While Utp in use)
  • Easy Icon Driven OSD Menu with Built-in Joystick
  • Programmable Privacy Zones
Introducing
CleanView™ technology repels water and dust to maintain a camera's image quality. A technologically-advanced coating alleviates spotting and smudges that affect the camera's performance.
Star-Light™ Super Low Light Technology
Star-Light™ Technology provides crisp clear images in both color and Black and White in extreme low light conditions. Star-Light technology offers a slow shutter feature that increases the length of time the shutter remains open to collect additional light, illuminating typically dark environments. The technology also utilizes Digital Noise Reduction and Highlight Masking Exposure to enhance the image clarity, offering a clear image in any lighting condition.
Digital Wide Dynamic Range (DWDR)
Digital Wide Dynamic Range technology uses the camera technology to capture an entire scene in challenging lighting conditions. The camera digitally adjusts the exposure to the dark areas and the bright areas at the same time, capturing both areas with no loss of detail.
Smart IR™
Smart IR™ adjusts the image for IR cameras to eliminate LED light reflection and white spots in the image. By breaking down the camera’s field of view into five zones, Smart IR allows for even distribution of the IR light. This prevents excessive illumination on images that are in the front of the scene and offers a clear image in B/W without any loss of detail.
Smart DNR™ 3D Digital Noise Reduction
Smart DNR™ 3D Digital Noise Reduction increases the camera’s clarity in very low light environments by using a unique algorithm to clean electronic noise signals that can reduce the camera’s visibility and trigger false motion detection events. Digital Watchdog’s special noise reduction technology allows the camera to produce clearer images in both color and B/W in low light without creating lag or ghost effects in the image.
TDN [True Day/Night] with IR Cut Filter
During daylight, the IR cut filter allows visible light to pass through, reflecting the unwanted infrared light. In low light environments, where artificial or external light is not available, the cut filter is removed from in front of the lens, allowing the camera to capture the infrared light that given out from the infrared LEDs, to capture as much light as possible to produce brighter images.
  • DWC-D3763WTIR
    STAR-LIGHT AHD™ 2.1 Megapixel HD Analog Indoor Dome Camera with IR
  • DWC-B6763WTIR
    STAR-LIGHT AHD™ 2.1 Megapixel HD Analog Indoor/Outdoor Bullet Camera with IR
  • DWC-V6763WTIR
    STAR-LIGHT AHD™ 2.1 Megapixel Indoor/Outdoor HD Analog Dome Camera with IR
  • DWC-B6763WTIR650
    STAR-LIGHT AHD™ 2.1 Megapixel Long Range HD Analog Indoor/Outdoor Bullet Camera with IR
  • DWC-PTZ20X
    STAR-LIGHT HD Coax PTZ™ 20X Pan Tilt Zoom Dome IP Camera
  • DWC-D3763TIR
    STAR-LIGHT AHD™ 2.1 Megapixel HD Analog Indoor Dome Camera with IR
  • DWC-MC753WTIR
    STAR-LIGHT AHD™ 2.1 Megapixel HD Analog Indoor Micro Dome Camera with IR
  • DWC-D4783WD
    STAR-LIGHT AHD™ 2.1 Megapixel HD Analog Indoor Snapit™ Dome Camera
  • DWC-D4783WTIR
    STAR-LIGHT AHD™ 2.1 Megapixel HD Analog Indoor Snapit™ Dome Camera with IR
  • DWC-B6763TIR
    STAR-LIGHT AHD™ 2.1 Megapixel HD Analog Indoor/Outdoor Bullet Camera with IR
  • DWC-V6763TIR
    STAR-LIGHT AHD™ 2.1 Megapixel HD Analog Indoor/Outdoor Dome Camera with IR
  • DWC-B7753TIR
    STAR-LIGHT AHD™ 2.1 Megapixel HD Analog Indoor/Outdoor Mini Bullet Camera with IR
  • DWC-V7753
    STAR-LIGHT AHD™ 2.1 Megapixel HD Analog Indoor/Outdoor Mini Dome Camera
  • DWC-V7753WTIR
    STAR-LIGHT AHD™ 2.1 Megapixel HD Analog Indoor/Outdoor Mini Dome Camera with IR
  • DWC-V7753TIR
    STAR-LIGHT AHD™ 2.1 Megapixel HD Analog Indoor/Outdoor Mini Dome Camera with IR
  • DWC-V4783WD
    STAR-LIGHT AHD™ 2.1 Megapixel HD Analog Indoor/Outdoor Snapit™ Dome Camera
  • DWC-V4783WTIR
    STAR-LIGHT AHD™ 2.1 Megapixel HD Analog Indoor/Outdoor Snapit™ Dome Camera with IR
  • DWC-C273W
    STAR-LIGHT AHD™ 2.1 Megapixel Indoor HD Analog Box Camera
  • DWC-VS753WT
    STAR-LIGHT FLEX™ 8 Megapixel User-Configurable Multi-Sensor Indoor/Outdoor AHD Camera
  • DWC-PB753WTW
    STAR-LIGHT PANO™ 6 Megapixel Multi-Sensor 180° Indoor/Outdoor Bullet AHD Camera
  • DW-VAC16
    VMAX AHD CORE 16-Channel
  • DW-VAC4
    VMAX AHD CORE 4-Channel
  • DW-VAC8
    VMAX AHD CORE 8-Channel

NEW! World’s First AHD LPR Camera.
Digital Watchdog® AHD LPR™ Camera is engineered to deliver the best performance in capturing license plates in extreme lighting conditions, from a range of 13 to 100 feet in moving vehicles up to 50mph. Analog High Definition (AHD) signal uses existing coaxial cable infrastructure while providing an unparalleled image quality up to 1640ft (500m) using RG59 cables. AHD technology leverages the robustness of analog signal infrastructure for a seamless upgrade to the details and clarity of 1080p high definition resolution. The camera's no fog or condensation under any conditions housing assures license plates are captured in any weather conditions.

Camera Features:
  • 1/3" Panasonic CMOS
  • AHD LPR™ License Plate Recognition Technology captures reflective license plates up to 50mph with a 13'-30' Capture Range
  • Reliable Performance under Any Lighting Conditions
  • External OSD and Lens Adjustment
  • 6-50mm Varifocal P-Iris Lens
  • Smart IR™ with Intelligent Camera Sync. 100ft Range
  • Secondary Video-BNC Output
  • OSD Control via Coax Cable using UTC
  • Easy Icon Driven OSD Menu with Built-in Joystick
  • No Fog or Condensation Under any Weather Conditions
  • IP66 Certified (Weather Resistant)




Record All Your Analog Cameras

All-in-One AHD, TVI and 960H Digital Video Recorder
The VMAX A1™ is a digital video recorder that offers real-time HD monitoring and recording up to 480fps at 960H and 720p and 240fps at 1080p (1920X1080) resolution. The VMAX A1™ supports analog signals up to 960H, TVI and Analog High Definition (AHD), leveraging the robustness of analog signal infrastructure for a seamless upgrade to the detail and clarity of 1080p high definition resolution. The A1™ is available in 4-, 8- and 16- channel configurations, can be configured with up to 12 Terabytes of internal storage and is backed by Digital Watchdog's unbeatable 5 year limited warranty.

View All Products Product Selector
Features:
  • Compatible with all 960H and below resolution Analog Cameras, AHD and TVI HD Formats (1080p via Coax) Resolutions
  • Pivot™ Central Management Software, Up to 128CH
  • Mobile Application for iPhone, iPad, iPod, Android Smart Phones and Tablets
  • MAC Compatible Remote ACS Software
  • Intuitive Graphical User Interface (GUI)
  • OSD and PTZ Control via Coax (UTC)
  • HDD Calculation and Auto Recording Configuration
  • Event Notifications via Email, Text and Pivot™ CMS
  • Advanced H.264 Embedded DVR
  • Multiplex - Live, Playback, Recording, Backup, Network, Configuration
  • 4-Channel Models: 60fps Recording in 1080p AHD or TVI Resolution, 120fps Recording in 1080p AHD or TVI Resolution
  • 8-Channel Models: 120fps Recording in 1080p AHD or TVI Resolution, 240fps Recording in all Analog Resolutions up to 960H and 720p
  • 16-Channel Models: 240fps Recording in all Analog Resolutions up to 960H and 720p, 480fps Recording in all Analog Resolutions up to 960H and 720p
  • 1 Audio Input, 1 Audio Output
  • 4 Sensor Input, 1 Relay Output
  • 16-Channel Looping Output (DW-VLOOP Module Not Included)
  • Simple & Free DDNS Service
  • Easy Web-Based Client with Multi-User Access
  • Help Menu on Major Functions
  • Auto & Manual Firmware Upgrade Available
  • 5 Year Limited Warranty
AHD, TVI and 960H Signal Support
The VMAX A1™ is the most simple way to upgrade an existing analog solution. With support for all 960H and below resolution Analog Cameras, AHD and TVI HD Formats (1080p via Coax) Resolutions, the DVR can be integrated into an existing application without the need to update the cameras at the same time. This allows for optimal financial flexibility and ROI, with individual components of an entire solutions updated separately.
PTZ and OSD Control via Coax (UTC)
UTC (Up The Coax) allows a user to access the camera's OSD (On Screen Display) through a coaxial connection, eliminating the need for an additional RS485 cable to reach the menu.
Pivot™ Central Management Software, Up to 128CH
128 channels from different sites and devices can be viewed simultaneously. Pivot™ provides the most advanced CMS system with a simple drag and drop camera viewing tool.
Event Notifications via Email, Text and Pivot™ CMS
The DVRs support event notifications for a variety of recording and system events. The notifications can be set to multiple e-mail accounts with attached screen shots, as a short text message, or event log to Pivot™ Remote Monitoring Software.
