Compressor™ 4-Channel IP Signal Encoder
Model: DW-CP04

Find a Reseller Request a Demo ContactUs

The CP-04 is an Analog to IP signal compressor, converting up to 4 analog cameras into IP signal at a maximum of 120fps at D1 resolution. The Compressor offers strong features such as Two-Way Audio, PTZ control, Micro SD Card for local backup, Intelligent motion detection, and Single Streaming with Dual Codec. The Compressor is a perfect solution for applications that have both analog and network surveillance solutions, and are looking to get the most out of both platforms.

  • 4CH Compressor

  • Audio Input/ Output: 1 Audio input, 1 Audio output
  • Central Management Software: DW Spectrum IPVMS
  • Codecs & Streams: H.264, MJPEG
  • Digital Zoom: Live and Playback
  • Firmware Upgrade: Auto via FTP Server and Manual
  • Multiple Recording Schedules: yes
  • OnVIF Conformant
  • Panic Recording
  • Remote Software Platforms: Windows, Linux, and MAC
  • Sensor Input/ Output: 4 Sensor inputs 4 Alarm outputs
  • Simple & Free DDNS: yes
  • Special Search Options: Convert analog video to IP signal at D1 resolution, Rs-485 and RS-232 command ports, local micro SD card for backup, periodical notifications to FTP server with screen shots
  • Watermark Verification [Digital Signature Authentication]
  • Web- Based Client with Multi- User Access: Live, PTZ Control, Playback, Remote Configuration
  • PTZ: Full analog PTZ camera control via RS-485 and RS-232 ports
  • Back Up: Remote Backup using the DW Spectrum IPVMS
  • Motion Detection
  • Recording Mode: Scheduled, Motion, Event
  • E-mail and Text Event Notifications: E-mail & FTP notifications with screen shot attached
  • Works with DW Spectrum™ IPVMS recording License (needs qty 1 DW-SPCP04LSC004, Sold Separately)
  • 2 years warranty

Environmental*


Power Requirements

12V (1A) [AC100~240V, 50/60Hz, 300mA]
Power Consumption

DC12: 600mA
Operating Temperature

-10 ~ 50°C (14 ~ 122°F)
Operating Humidity

Less than 90% (Non-Condensing)
Dimensions

5.82 X 4.64 X 0.98 in (148 x118 x25mm)
Weight

0.55lb (0.25Kg)
Available Models

DW-CP04

Network*


Client Monitoring Software

DW Spectrum (Synergy S/W)
IP Protocols

HTTP, RTP/RTSP, TCP/IP, FTP, Telnet, RARP, PPPoE, SNMP, PAP, CHAP, DHCP, NTP, SMTP client, uPNP
OnVIF Conformant


Transmission Speed- Live

120/100fps @ D1 (NTSC/ PAL)
Web Viewer Operations

Live, PTZ Control, Playback, Remote Configuration
Web Viewer Platforms

Internet Explorer 6.0 or higher. Minimum Client specifications: Windows XP, or higher, Pentium4, 2GHz, 2G(RAM), Video Card(256MB RAM, 1024x768)
Network Connection

Ethernet (1 x Megabyte 10/100 Base-T)

Performance*


Firmware Upgrade

USB Drive, Network Upgrade, IP Installer software
Playback Functions

Fast Forward, Fast Rewind, Frame-by-Frame Forward, Frame-by-Frame Rewind
Playback Rate

120fps
Playback Resolution

D1 Resolution
Recording Mode

Scheduled, Motion, Event
Recording Rate

120fps @ D1 Resolution
Recording Resolutions

120fps @ D1 Resolution
Search Modes

Date, Time, Event Preview
Special Features

Alarm Management, alarm and periodic notifications to FTP Server
Compression Type

H.264, MJPEG
Pre Alarm Recording

yes
Digital Zoom

Live and Playback
External Export Devices

Supports Micro SDHC for onboard storage ( up to 32 GB ) * SD Card not included

Video*


Audio Codec

8bit G.711, 8Khz, 8KByte/sec
Display Modes

Single Channel and Quad display modes
Maximum Supported Cameras

Up to 4 analog cameras
Serial Interface

1x RS-485 1x RS-232
Operating System

Embedded Linux
Video Input
BNC
4 BNC Input
Sensor Input

4 Sensor Inputs
Sensor Alarm Output

4 Alarm Outputs
Audio Input (RCA)

1 Channel Input
Audio Output

1 Channel Output
Warranty 2 years
DW Spectrum
DW-C19E
Rack mount ears - 19"
Title Type Size Download
Compressor Manual pdf 3.43 MB
Compressor Quick Start Guide pdf 0.08 MB
Compressor SmartPlayer Software cab 2.46 MB
Compressor SmartViewer Software cab 2.70 MB
Compressor Specifications pdf 0.56 MB
DW-CP04 AE specifications doc 0.08 MB
DW-CP04 data sheet pdf 0.84 MB
DW-CP04 Manual pdf 3.43 MB
DW-CP04 Quick Start Guide pdf 3.53 MB
DW-CP04 CAD Drawing dwg 0.18 MB
Title Type Version Compatibility Size Download
Compressor Firmware v4.25 Ext. URL v4.25 Compressor Firmware N/A
Compressor IP Installer zip v3.0.8 Compressor 1.10 MB
DW IP Finder v4.4.1 exe 22.95 MB
Frequently asked questions
Q. Security Hardening Tips
A.
  1. Limit amount of users that can have access to the dvr. Only have installer or owner/manager have full administrator rights to make any necessary changes.
  2. Change default HTTP and TCP ports; ports can be changed to any number as long as its not already in use by another device or service
  3. Change the password on the DVR system. If possible use a minimum of 8 alphanumeric characters.
  4. Make sure the system is behind a router or firewall.
  5. Ensure the firmware on the system is up to date. Firmware is important to fix any security or vulnerability issues that were not available when system was sent to distributor and to ensure that the system works as intended with no problems.
