Home HD over Coax Cameras DWC-B6563WTIR650W

DWC-B6563WTIR650W

Star-Light Plus 5MP UHDoC bullet camera with a long range vari-focal lens and IR
Find a Reseller Request a Demo Contact Us FAQs
Features
  • Universal HD over Coax® technology with HD-Analog, HD-TVI and HD-CVI signal support
  • Star-Light Plus™ color in near-total darkness technology
  • 1/2.8" image sensor
  • 5MP at 20fps, 4MP at real-time 30fps
  • 6~50mm vari-focal p-iris lens
  • True wide dynamic range (WDR)
  • OSD control via coaxial (UTC)
  • 150' Smart IR™ with intelligent camera sync.
  • Smart DNR™ 3D digital noise reduction
  • True day/night mechanical IR cut filter
  • De-Fog™ extreme weather image compensation
  • Auto-sensing 24VAC/12VDC with line lock
  • Easy icon-driven OSD menu with built-in joystick
  • Programmable privacy zones
  • Auto gain control (AGC)
  • Backlight compensation (BLC)
  • Auto white balance (AWB)
    • Show More

Learn about how DW
solutions can work for you

View All Markets

Megapixel resolution

DW’s technology delivers crystal-clear images in resolutions up to 5MP over coaxial infrastructure. Higher resolution delivers forensic details when zooming into the camera’s field of view.

Star-Light Plus™ color in darkness technology

Star-Light Plus™ color in near-total darkness technology provides crisp, clear images in the absence of ambient light.

Universal HD over Coax® Technology

Universal HD over Coax® Complete Solutions are the best way to upgrade an existing analog system to high-definition. Universal HD over Coax® cameras and recorders can transmit HD-Analog, HD-TVI, HD-CVI signals up to 4K, and analog signals to 960H.

Specifications

Active Pixels 2608 (H) x 1960 (V)
Frequency 50Hz, 60Hz
Image sensor 5MP 1/2.8" CMOS sensor
Maximum resolution 5MP, Analog CVBS: Up to 960H @ 30fps, HD-Analog and HD-TVI: 5MP/1944p @ 20fps and 12.5fps, HD-Analog, HD-TVI and HD-CVI: 2.1MP/1080p @ 30fp, HD-Analog, HD-TVI and HD-CVI: 4MP/1440p @ 30fps, HD-Analog, HD-TVI and HD-CVI: 720p @ 30fp
Minimum Scene Illumination in color 0.0 lux (B/W), 0.10 lux (color)
Scanning System Progressive scan
Signal technology CVBS up to 960H, HD-Analog, HD-CVI, HD-TVI, Universal HD over Coax® technology
Test Video Output CVBS video output for testing
Lens
Advanced Lens Features P-iris
Focal Length 6mm ~ 50mm
Horizontal Field of View (HFOV) 50.6° ~ 6.2°
IR Distance 150' range Smart IR™
Lens Type Vari-focal Lens
Vertical Field of View (VFOV) 27.4° ~ 3.5°
Operational
3D digital noise reduction Smart DNR™ 3D Digital Noise Reduction
Auto gain control Auto
Backlight compensation (BLC) Yes
Camera Control Pelco C, UTC, UTP built-in
Day and night Auto day/night, Day (color), Night (B/W)
De-fog Yes
Gamma 0.45
Mirror/flip Yes
Motion Detection Yes
Privacy Zones 24 programmable provacy zones
Sharpness Yes
Shutter Mode Auto
Shutter Speed 1/30 ~ 1/30000
Star-Light (sense up) Off, x2-x32
White Balance Yes
Wide Dynamic Range (WDR) True WDR 120dB
Environmental
Compliance CE  FCC  NDAA Compliance  RoHS
Environmental Operating Humidity 10-90% (non-condensing)
Environmental Operating Temperature -4°F ~ 122°F (-20°C ~ 50°C)
Mounting Accessories (Required/Optional) Optional. Sold separately
Mechanical
Camera Dimensions (H X W X D) *Dimensions based on the position of the sun shield cover, 9.92" x 3.8" (252 x 96.7 mm)
Camera Weight 1.76 lbs (0.8kg)
Housing Bullet
IP rating Weather Resistant (IP66)
Materials Aluminum die-casting
Electrical
American wire gauge (AWG) Cable type #18
Power Consumption AC24V (LED on): 5.6W, 233.3mA, AC24V (no LED): 2.86W, 119.1mA, DC12V (LED on): 6.2W, 531mA, DC12V (no LED): 3.3W, 275mA
Power Requirements 24 V AC
General
Warranty 5 Year Warranty

Accessories

DWC-V1CNMW
Corner and pole mount bracket - White
Learn more
DWC-BLJUNC-W
Junction box for white bullet cameras - white
Learn more
DWC-PMB-WLW
Pole mount bracket - white
Learn more

Documents

Title Type
Camera part numbering system
pdf Download
DW Accessories Chart
pdf Download
DWC-B6563WTIR650 data sheet
pdf Download
DWC-B6563WTIR650 quick setup guide
pdf Download
DWC-B6563WTIR650W datasheet
pdf Download
DWC-B6563WTIR650W quick setup guide
pdf Download
DWC-B6563WTIR650_W AE specifications
doc Download
DWC-B6563WTIR650_W CAD drawings
dwg Download
DWC-B6563WTIR650_W user manual
pdf Download
Star-Light Plus brochure
pdf Download
View All Documents
