Home IP Cameras DWC-PVX16WW, DWC-PVX16W2W, DWC-PVX16W4W

DWC-PVX16WW
DWC-PVX16W2W
DWC-PVX16W4W

MEGApix Flex 16MP multi-sensor vandal dome IP camera with fixed lens options
Find a Reseller Request a Demo Contact Us FAQs
NDAA
Features
  • 16MP 1/3" image sensors at real-time 30fps
  • 360° and 180° flexible panoramic view IP camera
  • Available as a complete system with 4x 2.8mm or 4x 4.0mm lens modules or camera and other lens options sold separately.
  • Four cameras in one installation
  • Flexible sensor positioning with magnets
  • True wide dynamic range (WDR)
  • PoE injector included
  • Dual codecs (H.264, MJPEG) with simultaneous dual-stream
  • Two-way audio
  • Smart DNR™ 3D digital noise reduction
  • True day/night with mechanical IR cut filter
  • Auto gain control (AGC)
  • Auto white balance (AWB)
  • Motion detection
  • 4x Micro SD/SDHC/SDXC class 10 card (card not included)
  • Alarm sensor input
  • Relay output
    • Show More

Easy 3-axis gimbal tilt and rotation

Each sensor has a 3-axis gimbal to fine-tune the Field of View (FoV) configuration, with endless 360° rotation and up to 60° tilting per sensor.

Flexible sensor positioning with magnets

Users can easily place each of the four sensors independently in any configuration around the camera's magnetic base. Use one installation to monitor a hallway or to produce a 270° view at building corners and large rooms.

Flex camera typical installations

Flex cameras can be personalized to match any application and any field of view (FoV) from a 180° panoramic view installation to a full 360° hemispheric FoV, all with a single camera and max flexibility.

Megapixel resolution in multi-sensor IP cameras

DW’s technology delivers crystal clear images in any resolution. Higher resolution offers forensic details with zooming into the camera’s field of view.

Specifications

Image sensor 4MP 1/3" CMOS sensor (x4)
Maximum resolution 16MP
Minimum Scene Illumination in color 0.41 lux (color)
Test Video Output Local video output CVBS 1.0V p-p (75Ω), 4:3 aspect ratio
Total Pixels 4x 2688 (H) x 1520 (V)
Lens
Focal Length 2.8mm, 4.0mm, 6.0mm, 8.0mm combinations (x4)
Horizontal Field of View (HFOV) 39°, 51°, 81°, 90°
Lens Type Fixed Lens
Vertical Field of View (VFOV) 22°, 29°, 43°
I/O
Audio compression G.711
Audio frequency response 50Hz ~ 10KHz
I/O Alarm in/out 1 input, 1 output
I/O Audio in/out 1 input, 1 output
Operational
3D digital noise reduction Smart DNR™ 3D Digital Noise Reduction
Auto gain control Auto
Day and night Auto day/night, Day (color), Night (B/W)
De-fog Yes
Memory slot 4x Micro SD/SDHC/SDXC class 10 cards (cards not included), Upto 1TB micro SD / exFAT
Mirror/flip Yes
Motion Detection Yes
Operational features True D/N
Operational Notifications Email, FTP server, Alarm output activation, SD card recording
Privacy Zones 16 programmable privacy masks
Shutter Mode Auto, Manual, Shutter Priority
Shutter Speed 1/15 ~ 1/32000
Slow Shutter Speed Off, x2, x3, x5, x7.5, x10
White Balance Yes
Wide Dynamic Range (WDR) True WDR 120dB
Network
Bitrate Control Multi-streaming CBR/VBR at H.264 (controllable frame rate and bandwidth)
IP IPv4, IPv6
LAN 1000Base-T (1Gbps)
Network resolution H.264: 1440p, 2.1MP/1080p, 720p, VGA, D1, CIF, MJPEG: 800x600, VGA, 768x432, D1, CIF
Network Web Viewer Windows® OS, Mac® OS, Linux® OS, Internet Explorer® browser, Google Chrome® browser, Mozilla Firefox® browser
Protocol 802.1x, ARP, Bonjour, DDNS, DHCP, DNS, FTP, HTTP, HTTPs, ICMP, NTP, ONVIF, PPPoE, QoS, RTCP, RTP (UDP/TCP), RTSP, SMTP, SNMPv1/v2/v3 (MIB-2), SSL, Syslog, TCP/IP, Telnet, UDP, Zeroconf (AutoIP)
Security HTTPS (TLS), IP filtering, MAC filtering, 802.1x, Digest authemtication (ID/PW), Multi-user authority
Stream Speed Up to 30fps at all resolutions
Video Bitrate 100Kbps~10Mbps, multi-rate for preview and recording
Video Compression Type H.264, MJPEG
Video Management Software DW Spectrum® IPVMS, Any ONVIF conformant CMS
Environmental
Compliance NDAA Compliance, UL Listing  CE, FCC
Environmental Operating Humidity 10-90% (non-condensing)
Environmental Operating Temperature -4°F ~ 122°F (-20°C ~ 50°C)
Mounting Accessories (Required/Optional) Optional. Sold separately
Mechanical
Camera Dimensions (H X W X D) 7.48" x 3.54" (190 x 90 mm)
Features Cleanview
Housing Vandal Dome, Panoramic
IP rating Weather Resistant (IP66)
Materials Aluminum die-casting, Polycarbonate lens cover
Weight 4.40 lbs (2kg)
Electrical
Power Consumption DC12V: max 18.0W, 1.5A, PoE: max 18.0W
Power Requirements IEEE 802.3at PoE+ class 4, (High power PoE injector included), 12V DC
General
Warranty 5 Year Warranty

Part Numbers

The camera is available in two ways:
  1. Complete solution: DWC-VPX16W2W and DWC-VPX16W4W. Includes 4 x 2.8mm or 4x 4.0mm fixed lens modules installed.
  2. Custom order: DWC-PVX16WW base unit + your selection in any combination of 2.8mm, 4.0mm, 6.0mm or 8.0mm fixed lens modules. Mix lens modules to best fit your individual needs. For example, select 1-2.8mm, 2-6.0mm and 1-8.0mm. Base unit and lens modules sold separately.

Model #

Details

DWC-PVX16W2W
Camera base + 4 x 2.8mm fixed lens modules, installed.
DWC-PVX16W4WCamera base + 4 x 4.0mm fixed lens modules, installed.
DWC-PVX16WW
Camera base. Lens sold separately. Please refer to the part numbers below.
DWC-PVXLMOD28

2.8mm fixed lens module. Must be purchased with DWC-PVX16WW camera base.
DWC-PVXLMOD4

4.0mm fixed lens module. Must be purchased with DWC-PVX16WW camera base.
DWC-PVXLMOD6

6.0mm fixed lens module. Must be purchased with DWC-PVX16WW camera base.

DWC-PVXLMOD8

8.0mm fixed lens module. Must be purchased with DWC-PVX16WW camera base.

Accessories

DWC-PZCMW
Ceiling mount bracket for multi-sensor cameras
Learn more
DWC-PZHMW
Hanging mount for selected multi-sensor cameras
Learn more
DWC-PZPARAMW
Parapet mount (requires DWC-PZADPW or DWC-PV20ADPW tilting adapter, sold separately)
Learn more
DW-PZADPW
Tilting adapter for DWC-PZARAMW and multi-sensor cameras
Learn more
DWC-PZWMW
Wall mount bracket for multi-sensor cameras
Learn more
DWC-V1CNMW
Corner and pole mount bracket
Learn more
DWC-WMJUNCW
Junction box for wall mount brackets
Learn more
DWC-PMB-WLW
Pole mount bracket
Learn more

Documents

Title Type
Camera part numbering system
pdf Download
DW Accessories Chart
pdf Download
DWC-PVX16W CAD Drawing
dwg Download
DWC-PVX16W user manual
pdf Download
DWC-PVX16WW datasheet
pdf Download
DWC-PVX16WW quick setup guide
pdf Download
DWC-PVX16Wx AE specifications
docx Download
MEGApix Flex Brochure
pdf Download
MEGApix Pano solutions brief
pdf Download
View All Documents
