Home Products Star-Light Plus™ Universal HD over Coax® 5MP Ultra Low-Profile Vandal Dome Camera with 2.8mm Lens

  • DOWNLOAD HIGH-RES PHOTO
Share this Product!
Star-Light Plus™ Universal HD over Coax® 5MP Ultra Low-Profile Vandal Dome Camera with 2.8mm Lens
Model: DWC-V7553W

Find a Reseller Request a Demo ContactUs

Featuring Star-Light Plus™ color in darkness, 5MP Star-Light Plus™ Universal HD over Coax® cameras deliver crystal-clear images and support HD-Analog, HD-TVI and HD-CVI signals. The ultra low-profile weather-resistant vandal dome cameras are IP66 rated and can be controlled via the same coax cable using UTC. All DW® Universal HD over Coax® cameras are engineered to work with our VMAX® A1 Plus™ DVRs using your existing coax infrastructure for a cost-effective, high-resolution surveillance solution.
  • DWC-V7553W

  • Universal HD over Coax® technology with HD-Analog, HD-TVI and HD-CVI signal support
  • Star-Light Plus™ super low-light technology
  • 1/2.8" image sensor
  • 5MP at 20fps, 4MP at real-time 30fps
  • 2.8mm fixed lens
  • True wide dynamic range (WDR)
  • OSD control via coaxial (UTC)
  • Ultra low-profile vandal dome housing
  • Smart DNR™ 3D digital noise reduction
  • De-Fog™ extreme weather image compensation
  • Easy icon driven OSD menu with built-in joystick
  • Programmable privacy zones
  • Auto gain control (AGC)
  • Backlight compensation (BLC)
  • Auto white balance (AWB)
  • IP66 environmental-rated dust-tight and water-resistant
  • IK 10-rated impact-resistant
  • 5 year warranty

Image sensor
5MP 1/2.8" CMOS
Active pixels
2608 (H) x 1960 (V)
Scanning system
Progressive scan
Frequency
60Hz / 50Hz
Signal technology
Universal HD over Coax® technology with HD-Analog, HD-TVI and HD-CVI signal support
Synchronization
Internal
Resolution
2592 x 1944 (5MP)
Minimum scene illumination
0.13 lux (color)

S/N ratio
55dB
Video output
HD-Analog and HD-TVI: 5MP/1944p @ 20fps and 12.5fps
HD-Analog, HD-TVI and HD-CVI: 4MP/1440p @ 30fps
2nd video output CVBS output for video testing

LENS
Focal length
2.8mm
Lens type
Fixed lens
Field of view (FoV)
103°

OPERATIONAL
Shutter mode
Auto
Shutter speed
1/30-1/30,000
Backlight
Yes
Star-Light (sense-up)
Off – x32
Wide dynamic range (WDR)
True WDR, off, on
Wide dynamic range (WDR) dB
120dB
Smart DNR™ 3D digital noise reduction
3D/2D DNR
White balance
Yes
Day / night
Auto, day (color), night (B/W)
Mirror / flip
Yes
Auto gain control
Max 72dB
Motion detection
Yes
Privacy zones
Yes
Sharpness
Yes
Gamma
0.45
De-fog
Yes
RS485 / UTP built-in
UTC

ENVIRONMENTAL
Operating temperature
-4°F ~ 122°F (-20°C ~ 50°C)
Operating humidity
10–90% RH (non–condensing)
IP rating
IP66 environmental-rated dust-tight and water-resistant
IK rating IK 10-rated impact-resistant
Other certifications
FCC, CE, ROHS

ELECTRICAL
Power requirement
DC12V only
Power consumption
DC12V: 2W DC12V

MECHANICAL
Material
Aluminum vandal housing, polycarbonate dome
Dimensions
4.13" x 2.38" (105 x 60.7mm)
Weight
0.88 lbs (0.4kg)
Star-Light Plus™ cameras
VMAX® A1 Plus™ DVRs
C3™ CMS
DWC-D3563WTIR
Star-Light Plus™ Universal HD over Coax® 5MP Indoor Dome Camera with Vari-focal Lens
DWC-V7DECO
Decorative rings for V7 ultra low-profile vandal dome cameras
DWC-V1CM
Ceiling mount bracket for V1 outdoor dome cameras
DWC-V7CM
Ceiling mount bracket for V7 outdoor dome cameras
DWC-GPLT
Converter plate for electronic gang box - ivory
DWC-GPLT-W
Converter plate for electronic gang box - white
DWC-V7JUNC
Junction box for V7 outdoor dome cameras
DWC-V7WM
Wall mount bracket for V7 outdoor dome cameras
Title Type Size Download
Camera Accessories Compatibility Chart pdf 3.88 MB
DWC-V7553W AE specifications doc 0.09 MB
DWC-V7553W CAD drawings dwg 0.22 MB
DWC-V7553W data sheet pdf 0.40 MB
DWC-V7553W data sheet (French) pdf 0.40 MB
DWC-V7553W data sheet (Spanish) pdf 0.40 MB
DWC-V7553W quick setup guide pdf 1.28 MB
DWC-V7553W_TIR user manual pdf 1.11 MB
Star-Light Plus brochure pdf 3.18 MB
