Blackjack® NAS 3U 16-bay chassis storage for Blackjack® servers
Model: DW-BJ16NASxTR

Find a Reseller Request a Demo ContactUs

Blackjack® NAS™ rack mount models are high-reliability network attached storage devices for Blackjack® E-Rack™ and X-Rack™ Servers and any network-attached computer or recorder. The 8 and 16 bay rackmount models act as primary or backup recording for existing DW Spectrum® IPVMS systems. Models offer 80TB and 160TB storage with RAID5 activated easily by a single click of the mouse. Additional hardware features include hot-swappable HDDs and dual power supply. Blackjack® NAS™ devices integrate easily into a Blackjack® E-Rack™ or X-Rack™ system with a total of up to 600Mbps throughput, allowing you to record and backup more days of video without the need for additional video recorders. The Blackjack® NAS™ integrates seamlessly into a DW Spectrum® IPVMS system, allowing for an instant search and data management and is backed by DW®’s unbeatable 5 year warranty.
  • DW-BJ16NASxTR

Centralize your file storage, sharing and backup with excellent performance
The Blackjack® NAS products offer the ideal supplement for existing systems with optimized network load and continuous archiving. Critical video and audio can be stored for longer time.
Easily Add Storage Capacity.
Blackjack® NAS devices can be implemented into a MEGApix® CaaS™ network with up to 12 cameras, or a Blackjack® Cube™ or Blackjack® Bolt™ network with up to 160Mbps throughput (the equivalent of 32 2.1MP cameras). The Blackjack® NAS offers lower cost and greater flexibility than adding additional servers to an existing system.
Add and manage recording from the DW Spectrum® IPVMS client software
The Blackjack® NAS units are integrated into the DW Spectrum® IPVMS software, allowing for simple addition, removal and recording setup all done from the same user-friendly UX of the DW Spectrum® IPVMS client.
  • Centralize your file storage and backup with excellent performance
  • Expands recording capacity of any Blackjack® NVR system
  • Add and manage recording for your NAS station directly from the DW Spectrum® IPVMS client software
  • Seamless search via the DW Spectrum® IPVMS client, including smart motion search, spyglass and calendar search options.
  • Add a NAS station to a Blackjack® E-Rack server with up to 128 cameras to quickly expand local storage and backup capacity at up to 600Mbps throughput.
  • Storage options 80TB and 160TB internal storage
  • RAID 5
  • Proprietary Linux® embedded OS
  • Redundant power supply
  • Hot swappable drives
  • Rail kit included
  • 5 year warranty
Operating System
Proprietary Linux® Embedded
Form factor
19'' Rack Mount (3U)
Flash memory
N/A
Maximum hard drives
16x 3.5" hot swappable HDDs
Maximum storage capacity
140TB
RAID
RAID 5
Max. recording channel
Max 128 2.1MP cameras with Blackjack® E-Rack
Max. recording bandwidth
Max. 600Mbps throughput
LAN
4x Gigabit Ethernet (RJ45)*
File service protocol
iSCSI(IP-SAN)**
Network protocol
iSCSI(IP-SAN), DHCP, HTTP, TCP/IP, UDP/IP, SNMP v1/v2c/v3, SMTP, DNS, NTP
Max. iSCSI Volume
4 (default 2)
Storage file system
Windows®: NTFS***
LED indicators
Power, activity and status(error)
LCD
RAID status, HDD status, network status (IP info), model info (model name and serial number), firmware info
Audible alert
RAID error
E-mail notifications (optional)
HDD status
Remote configuration
Blackjack® NAS web management console, DW IP Finder™
Supported IPVMS
DW Spectrum® IPVMS
Supported browsers
Microsoft® IE® 10 or higher
Google® Chrome® 57 or higher
Mac® Safari® 9 or higher (required)
Firefox® 43 or higher

USB output
2 USB pot. May used for upgrading FW via USB thumb drive. Not being used for connecting to USB HDD.


Operating temperature
41°F~104°F (5°C~40°C)
Humidity
20~90% (RH) non-condensing
Power supply
Dual SMPS 520W redundant, hot swappable 100 ~ 240 VAC; 50/60 Hz, 5.8~4A at 100/240VAC


Dimensions (WxDxH)
17.4'' x 5.2'' x 23.4''(442 x 133 x 595 mm)
Weight
Net: 35.3lbs(16.0 Kg)
Warranty
5 year
Client Requirements
CPU: Intel® 6th generation i7® or higher RAM: 16GB OS: Windows® 7 or higher, Windows® server 2008/2012 (Linux® compatible option coming soon)
* Only one Ethernet port will be used
** Require ISCSI Initiator on the server running DW Spectrum Media Server
***Ubuntu compatible coming soon

Model #

Max throughput

Usable RAID Storage Size

DW-BJ16NAS80TR
Up to 600Mbps throughput for Blackjack® E-Rack
70TB
DW-BJ16NAS160TR
Up to 600Mbps throughput for Blackjack® E-Rack
140TB
Client requirements:
  • CPU: Intel® 6th generation i7® or higher
  • RAM: 16GB
  • OS: Windows® 7 or higher, Windows® server 2008/2012
    (Linux® compatible option coming soon)
