Blackjack Tower mid-size servers with Intel® Core™ i3 processor
Model: DW-BJMT31xxT

Blackjack® Tower™ mid-size servers are reliable and high-performance solutions for recording multiple IP cameras of any resolution at up to 180Mbps throughput. The servers are UL-listed and NDAA/TAA compliant and include Windows 10® or Linux® Ubuntu® OS on a separate SSD. Hardware features include a 9th generation Intel® Core™ i3 processor, 8GB RAM, dual network cards and local output up to 4K resolution for system configuration. The servers come preloaded with DW Spectrum® IPVMS and four recording licenses, provide up to 20TB internal storage, are ONVIF conformant and come with a 5 year limited warranty.

All Blackjack® Tower servers come with one (1) DW-SPECTRUMLS004 4-channel license included.
For additional license part numbers click here

NDAA TAA


  • Blackjack Tower mid-size UL DW-BJMT31xxT

Max throughput and IP camera support
This Blackjack® server can record and manage single-sensor and multi-sensor IP cameras of any resolution up to 180Mbps throughput.
OS on dedicated SSD
DW’s servers provide a dedicated SSD for the OS. This results in faster boot time, faster application loading times and improved system responsiveness.
DW Spectrum® IPVMS
DW Spectrum® IPVMS is an endlessly customizable IP Video Management platform that gives users the ability to create tailored network video solutions for any type of project, from the office or on in the field.
ONVIF® Conformant
DW’s ONVIF conformant IP products allow you to bring our robust solutions to any surveillance system with other ONVIF components, creating a truly unique solution, to match your specific needs.
Designed and commissioned in the U.S.A
All DW recorders, workstations and NAS devices are designed, assembled and inspected in our California facility. Each product undergoes multiple levels of quality control to guarantee the highest quality and performance.
  • Supports all ONVIF conformant IP cameras
  • Up to 20TB internal storage
  • OS on SSD
  • Record and manage single- and multi-sensor IP cameras of any resolution up to 180Mbps throughput
  • 1 x True HD, 1 x DVI, 1 x VGA, for system configuration, 1 display output at a time
  • Dual network ports
  • Windows 10®  and Ubuntu® Linux® OS options
  • Hosting DW Spectrum® for setup, configuration and recording
  • One-time recording license charge, fully transferable between cameras and encoders
  • One (1) 4-channel license included (DW-SPECTRUMLSC004)
  • No annual maintenance fees
  • Simple enterprise scalability
  • Auto device discovery
  • Dual-stream recording
  • USB mouse and keyboard included
  • Designed, assembled and tested in the U.S.A.
  • UL Listed
  • NDAA/TAA compliant
  • 5 year limited warranty
MODELS
DW-BJMT31xxT/LX DW-BJMT51xxT/LX DW-BJMT71xxT/LX
Included IP licenses
4 4 4
Form factor
Mid-size tower Mid-size tower Mid-size tower
Operating system
Windows® 10 DW-BJMT31xxT DW-BJMT51xxT DW-BJMT71xxT
Linux Ubuntu® DW-BJMT31xxTLX DW-BJMT51xxTLX ---
Windows Server® --- --- DW-BJMT71xxTS
OS on SSD 240GB SSD 240GB SSD 240GB SSD
CPU
9th generation Intel® i3® processor
9th generation Intel® i5® processor
9th generation Intel® i7® processor
Memory
8GB 16GB 16GB
Ethernet port
2 x 1Gigabit Ethernet (RJ45) 2 x 1Gigabit Ethernet (RJ45) 2 x 1Gigabit Ethernet (RJ45)
System
Max video storage rate (Mbps)
180Mbps 360Mbps 480 Mbps
Storage
Maximum storage drives
3 x 3.5 SATA HDD 3 x 3.5 SATA HDD 3 x 3.5 SATA HDD
Maximum storage
20TB 30TB 30TB
Video-out
Outputs
1 x true HD, 1 x DVI, 1 x VGA. Maximum 1 display output at a time
Video card
Onboard Intel graphics
Preloaded VMS software
DW Spectrum® IPVMS
Remote clients
Cross-platform - Windows®, Linux® Ubuntu® and Mac®
Mobile apps
iOS® and Andriod®
Keyboard and mouse
Included
Power supply
400W** 400W** 400W**
Operating temperature (ambient room temperature)
41°F~104°F (5°C~40°C)
Operating humidity
20~90% RH
Dimension (WxDxH)
7.46” x 15.7” x 14.21” (189.52 x 398.8 x 631.02 mm)
Other certifications UL listed, ONVIF, NDAA/TAA, CE, FCC
Warranty
5 year limited

** A UPS is recommended

Part Number

Description

DW-BJMT3102T, DW-BJMT3102TLX
9th generation Intel® i3® processor, 2TB.
DW-BJMT3104T, DW-BJMT3104TLX
9th generation Intel® i3® processor, 4TB.
DW-BJMT316T, DW-BJMT316TLX
9th generation Intel® i3® processor, 6TB.
DW-BJMT31012T, DW-BJMT31012TLX
9th generation Intel® i3® processor, 12TB.
DW-BJMT31016T, DW-BJMT31016TLX
9th generation Intel® i3® processor, 16TB.
DW-BJMT3120T, DW-BJMT3120TLX 9th generation Intel® i3® processor, 20TB.

* For Linux OS models, add LX at the end of the part number.
DW Spectrum IPVMS Licensing Options

Part Number

Description

DW-SPECTRUMLSC001
Single DW Spectrum® IPVMS License, No Annual Renewal, No Upgrade Required.
DW-SPECTRUMLS004
Four (4) DW Spectrum® IPVMS Licenses, No Annual Renewal, No Upgrade Required.
DW-SPECTRUMLS010
Ten (10) DW Spectrum® IPVMS Licenses, No Annual Renewal, No Upgrade Required.
DW-SPECTRUMLS020
Twenty (20)  DW Spectrum® IPVMS Licenses, No Annual Renewal, No Upgrade Required.
DW-SPECTRUMLS050
Fifty (50)  DW Spectrum® IPVMS Licenses, No Annual Renewal, No Upgrade Required.
DW-SPECTRUMLS100
One Hundred (100)  DW Spectrum® IPVMS Licenses, No Annual Renewal, No Upgrade Required.
DW-SPCP04LSC004
Single DW Spectrum® IPVMS License - allows up to 4-channel or recording when used with DW-CP04 and DW-CP16,  No Annual Renewal, No Upgrade Required.
DW-SPVWALL1X2Single DW Spectrum® IPVMS Video Wall License - 1 Operator, 2 Monitors,  No Annual Renewal, No Upgrade Required.
