MEGApix® 4K PTZ IP camera with 6~180mm vari-focal lens with motorized zoom and auto-focus and 30x optical zoom and IR
Model: DWC-MPTZ830XW
DISCONTINUED


The MEGApix® 30x PTZ Camera delivers crystal-clear 4K resolution at real-time 30fps. The camera is powered by Star-Light Plus™ technology for outstanding color in near-total darkness. Features include 30x optical zoom and Smart IR™ up to 1148ft (350m) in an IP66-rated, IK-10 impact-resistant vandal housing. A wall mount and ceiling mount are sold separately and are required to complete the camera's installation.


  • DWC-MPTZ830XW

30x Optical zoom
The optical zoom lens uses internal glass elements to bring an image up to 30x closer, allowing the magnified image to be recorded at full resolution.
Megapixel resolution
DW’s technology delivers crystal clear images in any resolution. Higher-resolution offers forensic details with zooming into the camera’s field of view.
  • 4K 1/1.7" image sensor at real-time 30fps
  • Star-Light Plus™ color in near-total darkness technology
  • 6~180mm vari-focal lens with motorized zoom and auto-focus
  • True wide dynamic range (WDR)
  • Multiple codecs (H.265, H.264, MJPEG) with simultaneous dual-stream
  • 30x optical zoom
  • 1148' (350m) Smart IR™ with intelligent camera sync
  • Smart DNR™ 3D digital noise reduction
  • True day/night with mechanical IR cut filter
  • Programmable privacy zones
  • Backlight compensation (BLC)
  • Auto white balance (AWB)
  • Motion detection
  • Two-way audio
  • Pan 0~360° endless, 380° per second pan speed
  • Vector drive technology – pan/tilt motion in shortest path
  • 256 preset positions
  • 8 patterns
  • 8 tours
  • Micro SD/SDHC/SDXC class 10 card slot for emergency backup (card not included)
  • Alarm sensor input
  • Relay output
  • Web server built-in
  • PoE injector included
  • PoE class 4 and DC12V
  • ONVIF conformant, profile S
  • IP66 environmental-rated dust-tight and water-resistant
  • IK 10-rated impact-resistant


Image sensor
4K 1/1.7” CMOS sensor
Total pixels / active pixels
4168 (H) x 3062 (V), 3840 (H) x 2160 (V)
Minimum scene illumination
0.75 lux (color)
0.0 lux (B/W)

LENS

Focal length
6 ~ 180mm
Lens type
Vari-focal lens with motorized zoom and auto-focus
IR distance
1148 range
Angle of view
55.4° ~ 2.7°
Digital zoom / zoom
30x optical zoom

I/O

Audio input / output
1/1
Audio compression
G.711
Audio alert User-defined 3 audio files
Alarm input/ output
4/1
Manual triggers 4 programmable triggers

OPERATIONAL

Shutter mode
Auto, manual, flicker-free mode
Shutter speed
1/10,000 ~ x 1sec.
Backlight
Yes
De-fog
Yes
Wide dynamic range (WDR)
True WDR, off, low, middle, high
Wide dynamic range (WDR) dB
120dB
Smart DNR™ 3D digital noise reduction
2DNR, 3DNR
White balance
Auto, manual
Day and night
Auto, day (color), night (B/W)
Mirror / flip
Yes
Privacy zones
16 programmable privacy masks
Motion detection 16 programmable motion zones (8 include areas and 8 exclude areas)
Memory slot Micro SD/SDHC/SDXC card (not included).
SD card recording mode Event and continuous recording
Event buffering - FTP Pre: 30 seconds, post: 30 seconds
Event buffering - SD card Pre: 10 seconds, post: 60 seconds
Alarm notifications
Notifications via e-mail, FTP server, alarm output activation, audio output activation, preset activation, notification server, XML notifications or SD card recording.

PTZ FUNCTION

Pan range
360° endless
Pan speed
Max. 380°/sec. (preset)
Tilt range
-10~190°
Tilt speed
Max. 380°/sec. (preset)
Auto calibration
0.1~6°
Preset
256
Tour
8
Pattern
8
Home function
Yes

NETWORK

LAN
RJ-45 (10/100Base-T)
Video compression type
H.265 (main profile), H.264 (baseline, main, high profile), MJPEG
Resolution
3840x2160, 3072x2048, 2592x1944/1520, 2560x1440, 1920x1080,
1440x1080, 1280x1024/720, 1024x768, 800x600/480, D1, 640x480, 400x240, CIF
Video bitrate
100Kbps ~ 8Mbps, multi-rate for preview and recording
Frame rate
Up to 30fps at all resolutions
Streaming capability
Quad-stream (H.265x3, H.265x1, MJPGx1)
Bitrate control Multi-streaming CVBR/VBR at H.265, H.264 (controllable framerate and bandwidth)
IP
IPv4, IPv6
Protocol
TCP/IP, UDP, HTTP, HTTPS, QoS, FTP, UPnP, RTP, RTSP, RTCP, DHCP, ARP, Zeroconf, Bonjour
Security
Password authentication, multi-user authority, IP filtering, HTTPS (TLS)
Maximum user access
Live: 10 users, playback: 3 users
ONVIF conformance
Yes
Web viewer
OS: Windows®, MAC® OS, Linux®
Browser: Internet Explorer®
Network time sync
NTP server, synchronized computer, manual
Software reset Restart, reset, factory default
Remote upgrade Bakup and restore

ENVIRONMENTAL

Operating temperature
-22°F ~ 131°F (-30°C ~ 55°C )
Operating humidity
0–90% RH (non–condensing)
IP rating
IP66-rated
IK rating IK-10 impact-resistant
Other certifications
CE, FCC, RoHS

ELECTRICAL

Power requirement
DC 12V, PoE (UPoE, Class4), PoE injector included
Power consumption
PoE: 28W, 500mA
DC 12V: 28W, 2.3A

MECHANICAL

Material
Aluminum PTZ, polycarbonate dome
Dimensions
7.94 x 12.51 Inch (201.8 x 317.8 mm)
Weight
11.24 lb (5.1kg)
