DWC-MB45WiATW
DWC-MPB45WiATW

MEGApix 5MP bullet IP camera with a vari-focal lens and IR
Features
  • 5MP sensor at real-time 30fps
  • Star-Light Plus™ color in near-total darkness technology
  • Intelligent Video Analytics (IVA) with extended features (IVA+)
  • Seamless integration and control of IVA rules with DW Spectrum® IPVMS
  • Reduce false alarms
  • Increase your recording storage with logic rules and smart recording
  • Vari-focal p-iris lens with motorized zoom and autofocus for complete remote lens control and focused image any time
  • True Wide Dynamic Range (WDR) for clear images in challenging light
  • Simultaneous streaming and multiple codec options for smart bandwidth management
  • Cold Start -40°F (-40°C), allowing the camera to power up in extremely cold environments
  • 140' Smart IR™ with intelligent camera sync for clear B/W images with no need for external light
  • Smart DNR™ 3D digital noise reduction reduces noise and ghosting for motion in low-light environments.
  • Privacy zones cover sensitive areas in the camera's field of view.
  • Two-way audio for direct communication between the monitoring station and the camera's location
  • Local SD card slot for local recording in case of network loss
  • Web server built-in for easy camera management from any browser
  • PoE and DC12V for single cable simplified installation
  • Show More

Megapixel resolution

DW’s technology delivers crystal clear images in any resolution. Higher-resolution offers forensic details with zooming into the camera’s field of view.

Star-Light Plus™ color in darkness technology

Star-Light Plus™ color in near-total darkness technology provides crisp, clear images in the absence of ambient light.

IVA Analytics

MEGApix IVA cameras include a base package of Intelligent Video Analytics detection capabilities already activated on the camera and ready for deployment.

Learn More.

IVA+ Analytics

The MEGApix IVA+ package offers advanced rules to the IVA Video Content Analysis detection capabilities.

Learn More.

Cold Start -40°F (-40°C)

The installed heater helps the camera power up in extreme cold weather conditions where temperatures may go as low as -40°F. This makes the cameras ideal for any harsh environment installation.

True Wide Dynamic Range (WDR)

Cameras with True Wide Dynamic Range (WDR) technology have advanced sensors that can process a wider range of lighting, dark and bright in the same image.

H.265 codec support

High-Efficiency video codec standards deliver 25% to 50% better data compression while maintaining video quality.

Specifications

Active Pixels 4x 1944 (H) x 1092 (V)
Image sensor 5MP 1/2.8" CMOS sensor
Maximum resolution 5MP
Minimum Scene Illumination in color 0.0 lux (B/W), 0.08 lux (color)
Test Video Output Local video output CVBS 1.0V p-p (75Ω), 4:3 aspect ratio
Total Pixels 2592 (H) × 1944 (V)
Lens
Advanced Lens Features Auto focus, Motorized zoom, P-iris
Horizontal Field of View (HFOV) 85° ~ 31°
IR Distance 140' range Smart IR™
Lens Type Vari-focal Lens
Vertical Field of View (VFOV) 24° ~ 62°
I/O
Audio compression G.711
I/O Alarm in/out 1 input, 1 output
I/O Audio in/out *Cameras provide a line level audio. The use of amplified microphones and speakers is recommended., 1 input, 1 output
Intelligent Video Analytics
IVA license Intrusion, line crossing, counting line, loitering, enter, exit, tamper
IVA+ license Logical rules, object removed, tailgating, direction, stopped, appear, disappear, object left
Operational
3D digital noise reduction Smart DNR™ 3D Digital Noise Reduction
Auto gain control Auto
Day and night Auto day/night, Day (color), Night (B/W)
De-fog Yes
Memory slot Micro SD/SDHC/SDXC class 10 card (card not included), Up to 1TB micro SD / FAT32
Mirror/flip Yes
Motion Detection Yes
Operational Notifications Alarm output activation, Email, SD card recording
Privacy Zones 16 programmable privacy masks
Shutter Mode Auto, Manual, Slow Shutter
Shutter Speed 8 ~ 1/50000
Slow Shutter Speed Off, x15, x2, x3, x4, x5, x6, x7.5
White Balance Yes
Wide Dynamic Range (WDR) True WDR 120dB
Network
Bitrate Control Multi-streaming CBR/VBR at H.264 (controllable frame rate and bandwidth)
IP IPv4
Network resolution H.264: 2.1MP/1080p, 720p (main), CIF (sub), H.264: 3008x3000, 2800x2800, 2048x2048, 1600x1600, 640x640, 320x320, H.265: 3008x3000, 2800x2800, 2048x2048, 1600x1600, 640x640, 320x320, MJPEG: CIF
Network Web Viewer Google Chrome® browser, Linux® OS, Mac® OS, Microsoft Edge® browser, Mozilla Firefox® browser, Safari® browser, Windows® OS
Protocol Bonjour, DDNS, DHCP, DNS, Genetec Protocol, HTTP, HTTPs, IGMP, NTP, RTP, RTP (UDP/TCP), RTSP, SNMP, SNMPv1/v2/v3 (MIB-2), TCP, Telnet, UPnP, Zeroconf (AutoIP)
Security 802.1x, HTTPS (TLS), MAC filtering, Multi-user authority
Stream Speed Up to 30fps at all resolutions
Streaming Capability Dual-stream at different rates and resolutions
Video Bitrate 32Kbps~20Mbps
Video Compression Type H.264, H.265, MJPEG
Video Management Software DW Spectrum® IPVMS, ExacqVision Technologies, Genetec Inc., Milestone Systems
Environmental
Compliance CE  FCC  NDAA Compliance  ONVIF  UL Listing
Environmental Operating Humidity 10-90% (non-condensing)
Environmental Operating Temperature -40°F ~ 122°F (-40°C ~ 50°C)
Mounting Accessories (Required/Optional) Optional. Sold separately
Mechanical
Camera Dimensions (H X W X D) *Dimensions based on the position of the sun shield cover, 12.2” x 3.81” (310 x 97mm), 9.4” x 3.8” (264 x 96.7 mm)
Camera Weight 1.96 lbs (0.89 kg)
Housing Bullet
Housing Color White
IP rating Weather Resistant (IP66)
Materials Aluminum die-casting
Electrical
American wire gauge (AWG) Cable type #18
Power Consumption DC12V: max 9.0W, 750mA, PoE: max 10.5W
Power Requirements Adapter not included, PoE
General
Warranty 5 Year Warranty

Part Numbers

Part Number Description
DWC-MB45WiATW preloaded with IVA.
DWC-MPB45WiATW preloaded with IVA+.

Accessories

DWC-V1CNMW
Corner and pole mount bracket - White
Learn more
DWC-BLJUNC-W
Junction box for white bullet cameras - white
Learn more
DWC-PMB-WLW
Pole mount bracket - white
Learn more

Documents

Title Type
DWC-M(P)B45WiATW datasheet
pdf Download
DWC-M(P)B45WixxW series quick setup guide
pdf Download
Camera part numbering system
pdf Download
DW Accessories Chart
pdf Download
DWC-M(P)B45WiAT_W AE specifications
doc Download
DWC-M(P)B45WiAT_W CAD drawing
dwg Download
MEGApix IVA user manual - rules and analytics
pdf Download
MEGApix Single-Sensor Brochure
pdf Download
DWC-M(P)B45WiAT series user manual
pdf Download

Software

Title Type Release Notes Version Update Date Compatibility Size
DW IP Finder v4.4.22 for Linux OS run v4.4.22 01/18/2024 46.00 MB Download
DW IP Finder v4.4.22 for Windows OS exe v4.4.22 01/18/2024 27.76 MB Download
DW Spectrum Linux plug-in v2.3.40 for MEGApix IVA and Ai IP cameras gz 01/15/2024 0.43 MB Download
DW Spectrum Windows 64bit exe plug-in v2.3.40 for MEGApix IVA and Ai IP cameras zip 01/15/2024 0.78 MB Download
DW Spectrum Windows 64bit plug-in v2.3.40 for MEGApix IVA and Ai IP cameras zip 01/15/2024 0.56 MB Download
IVA and IVA+ plugin v.1.0.91 zip v.1.0.91 09/25/2023 14.06 MB Download
MEGApix® 5MP firmware vA6.2.3_20230823 img A6.2.3_20230823 09/18/2023 64.60 MB Download
