DW-BJCX

Blackjack CX 16-channel PoE NVR with 8 virtual channels
Find a Reseller Request a Demo Contact Us FAQs
NDAA TAA


Features
  • Supports all ONVIF conformant IP cameras
  • Storage options 8-40TB internal storage
  • Record and manage up to 24 IP cameras with local PoE support for 16 channels
  • Record and manage single- and multi-sensor IP cameras of any resolution up to 80Mbps throughput
  • Intel® processor
  • 1xTrue HD, 1x DVI, 1 display output at a time
  • Dual network ports
  • 4 alarm inputs, 2 alarm outputs
  • 1 audio input, 1 audio output, 1 microphone input
  • One-time recording license charge, fully transferable between cameras and encoders
  • One (1) 4-channel licenses included (DW-SPECTRUMLSC004)
  • No annual maintenance fees
  • Simple enterprise scalability and auto device discovery
  • Dual stream recording
  • Wall mount and rack mount ears available. Sold separately
  • USB mouse and keyboard included
  • DW-BJCXRM rack mount ears included with the recorder
    • Show More

Max throughput and IP camera support

This Blackjack® server can record and manage single-sensor and multi-sensor IP cameras of any resolution up to of 80Mbps throughput.

High power output per port

The Blackjack® CX™ PoE NVR delivers local power up to 15W simultaneous on all ports, giving customers significant versatility on camera choices and a simple plug-and-play setup.

Powered by DW Spectrum® IPVMS

Blackjack® CX™ recorders offer the full capabilities of DW Spectrum IPVMS without the hassle of wiring cameras to a power supply on an affordable stand-alone NVR.

Dual network cards

Optimize network bandwidth by utilizing dual network ports, to build a separate network for the surveillance system and keep that traffic off the main network, reserved for the NVR’s communication.

Designed and commissioned in the U.S.A

All DW recorders, workstations and NAS devices are designed, assembled and inspected in our California facility. Each product undergoes multiple levels of quality control to guarantee the highest quality and performance.

Specifications

Video
CPU Intel® Celeron processor
Data rate (Mbps) 80Mbps
Display Modes Unlimited, Sequence, Customizable
Input channels 24 Channels, 16 PoE channels
Local Video Output Resolution 4096 x 2160
Local Video Outputs True HD, 1 display output at a time, For initial configuration and server management
Memory 8GB
PoE Type 802.3af support 16 ports x 10/100 PoE, per port (240W max PSE)
Video Compression H.264, H.265
Video Operating System Linux® Ubuntu Desktop 20.04.3 LTS for IoT OS
OS on SSD m.2 SSD
Storage
Raw internal storage options 8TB  16TB  24TB  32TB  40TB
Max HDD Bay 2 x SATA HDD
Maximum Storage 40TB
RAID Options No RAID
Performance
Alarm in/out 2 alarm outputs, 4 alarm inputs, Terminal block
Audio in/out 1 input, 1 output
Performance features PoE built-in, Digital Zoom in live and playback
Playback Functions Timeline, Calendar, Event search, Thumbnail search, Smart motion search
PTZ control ONVIF
Recording Modes Continuous, Motion detection, Motion + low res always, Object only, Object + Low res, Motion + Object, Motion + Object + Low res
System Operation Graphical user interface (GUI), USB mouse (included), Remote via DW Spectrum IPVMS
Network
Backup Network backup via DW Spectrum IPVMS
Ethernet Ports 2x 1G Ethernet (RJ45)
Network Remote Software DW Spectrum Mobile App, Cross-platform - Windows®, Linux Ubuntu® and Mac®
Pre-loaded VMS software DW Spectrum® IPVMS
Electrical
Power Consumption 410W
Power Requirements 110~240V A/C
Total PoE Power Budget 240W
General
Accessories Keyboard, Mouse
Certification NDAA Compliance  ONVIF Conformant  TAA Compliance
Form Factor Slim Desktop
Included IP licenses 4
Operating Temperature and Humidity 10~90% RH, 32°F~104°F (0°C~40°C)
Recorder Dimensions (H X W X D) 1.75” (H) x 16.92” (W) x 13.7” (D) (44.5mm (H) x 430mm (W) x 348mm (D))
Recording Licenses (Optional. Sold Separately) DW-SPECTRUMLSC001 - Single DW Spectrum® IPVMS Recording License
DW-SPECTRUMLSC004 - Four (4) DW Spectrum® IPVMS Recording Licenses
DW-SPECTRUMLSC010 - Ten (10) DW Spectrum® IPVMS Recording Licenses
DW-SPECTRUMLSC020 - Twenty (20) DW Spectrum® IPVMS Recording Licenses
DW-SPECTRUMLSC050 - Fifty (50) DW Spectrum® IPVMS Recording Licenses
DW-SPECTRUMLSC100 - One hundred (100) DW Spectrum® IPVMS Recording Licenses
DW-SPCP04LSC004 - Four (4) DW Spectrum® Analog Encoder IPVMS Licenses
DW-SPIOLSC001 - Single DW Spectrum® I/O Module IPVMS License
DW-SPCP16LSC016 - Sixteen (16) DW Spectrum® Analog Encoder IPVMS Licenses
DW-SPVWALL1X2 - Single DW Spectrum® Video Wall IPVMS License
Custom-ordered licenses are available by request.
Lifetime upgrades are included with no annual renewal fees.
Serial ports RS485, ONVIF
USB interface Yes
Warranty 5 Year Limited Warranty

Part Numbers

Model #*

Internl Storage
DW-BJCX8T-LX 8TB internal storage
DW-BJCX16T-LX 16TB internal storage
DW-BJCX24T-LX 24TB internal storage
DW-BJCX32T-LX 32TB internal storage
DW-BJCX40T-LX 40TB internal storage

Purchasing Options

DW Spectrum IPVMS Licensing Options

Part Number

Description

DW-SPECTRUMLSC001
Single DW Spectrum IPVMS License, No Annual Renewal, No Upgrade Required.
DW-SPECTRUMLSC004
Four (4) DW Spectrum IPVMS Licenses, No Annual Renewal, No Upgrade Required.
DW-SPECTRUMLSC010
Ten (10) DW Spectrum IPVMS Licenses, No Annual Renewal, No Upgrade Required.
DW-SPECTRUMLSC020
Twenty (20)  DW Spectrum IPVMS Licenses, No Annual Renewal, No Upgrade Required.required.
DW-SPECTRUMLSC050
Fifty (50)  DW Spectrum IPVMS Licenses, No Annual Renewal, No Upgrade Required.
DW-SPECTRUMLSC100
One Hundred (100)  DW Spectrum IPVMS Licenses, No Annual Renewal, No Upgrade Required.
DW-SPCP04LSC004
Single DW Spectrum IPVMS License - allows up to 4-channel or recording when used with DW-ENHD16,  No Annual Renewal, No Upgrade Required.
DW-SPCP04LSC016
Single DW Spectrum IPVMS License - allows up to 16-channel or recording when used with DW-ENHD16,  No Annual Renewal, No Upgrade Required.
DW-SPIOLSC001 IP I/O Module License - Supported devices IP I/O Modules are automatically discovered and can be used to trigger system events, actions, and alerts.
DW-SPVWALL1X2Single DW Spectrum IPVMS Video Wall License - 1 Operator, 2 Monitors,  No Annual Renewal, No Upgrade Required.

Accessories

DW-BJCXRM (included with DW-BJCX)
19in rack mount ears
Learn more
DW-BJCXWM
Wall mount brackets
Learn more
DW-SPCP04LSC004
DW-SPCP04LSC004
Learn more
DW-SPCP16LSC016
DW-SPCP16LSC016
Learn more
DW-SPECTRUMLSC001
DW-SPECTRUMLSC001
Learn more
DW-SPECTRUMLSC004
DW-SPECTRUMLSC004
Learn more
DW-SPECTRUMLSC010
DW-SPECTRUMLSC010
Learn more
DW-SPECTRUMLSC020
DW-SPECTRUMLSC020
Learn more
DW-SPECTRUMLSC050
DW-SPECTRUMLSC050
Learn more
DW-SPECTRUMLSC100
DW-SPECTRUMLSC100
Learn more
DW-SPIOLSC001
DW-SPIOLSC001
Learn more
DW-SPVWALL1X2
DW-SPVWALL1X2
Learn more
