Video | |
---|---|
Display Modes | 1, 4, 9, 12, Sequence |
Display Speed | Up to 30fps per channel |
Input channels | 12 Channels |
Local Video Output Resolution | 1024x768, 1280x720, 1280x1024, 1920x1080, 2560x1600, 3840×2160 (4K) |
Local Video Outputs | True HD, VGA |
Max Supported Recording Resolution | 4K (3840×2160) |
Max video storage rate (Mbps) | 80Mbps |
PoE Type | 100Mbps, 802.3at |
Video Compression | H.264, H.265 |
Video Operating System | Embedded Linux® |
Storage | |
Raw internal storage options |
![]() ![]() ![]() ![]() ![]() ![]() ![]() ![]() ![]() ![]() |
Max HDD Bay | 4 x SATA HDD |
Maximum Storage | 24TB |
Performance | |
Performance features | PoE built-in, CCIP, Quick Setup under 3 Minutes, Snapshot Notify™: Programmable interval camera image verification sent to an email, Real-time temp alert, Digital Zoom in live and playback, Import and export settings, Covert Channel, Camera Color Control, Watermak exported video, AVI file backup |
Playback Functions | Timeline, Calendar, Event search, Thumbnail search, Smart motion search |
Playback speed | x1, x2, x4, x8, x16, x32, x64, x99 |
Post-recording | 0~5 minutes |
Pre- recording | 0~5 seconds |
PTZ control | RS485, ONVIF |
Recording Modes | Continuous, Scheduled, Sensor, Motion detection, Pre- and post-alarm, Emergency, Quick backup |
Recording Resolution and Recording Rate | Up to 3840×2160 (4K): 360fps |
System Operation | Remote Control (optional), Graphical user interface (GUI), USB mouse (included), Joystick Controller (optional) |
Network | |
Backup | Local backup via USB, Network backup via CMS |
Ethernet Ports | 1x 1G Ethernet (RJ45) |
Firmware Upgrade | FTP, USB, CMS over network |
Network Remote Software | Pivot CMS, DW VMAX App, DW Witness, DW Site Viewer for Apple TV, ACS VMAX Client for MAC, DW VMAX Plus App, C3 CMS, DW Mobile Plus |
Protocol | Static fixed IP, DDNS, DHCP, uPNP, RTSP |
System recovery after power failure | Auto-reboot and journaling file system |
Transation verification | Text-in Based (USB to Serial support, TCP/IP Network) |
Transmission speed live | Up to 3840×2160 (4K): 360fps |
Electrical | |
Power Consumption | 360W total power budget, 5.5A, 18.75W per PoE channel, simultaneous, A UPS is recommended |
Power Requirements | 110~240V A/C |
General | |
Accessories | Mouse, IR remote control (optional) |
Alarm in/out | 16 inputs, 4 outputs |
Audio in/out | 1 input, 1 output |
Certification |
ONVIF Conformant, ![]() |
Certification (Product Specification) | FCC, RohS, KCC, WEEE |
Form Factor | Embedded |
Maximum Power per Port | 30W |
Operating Temperature and Humidity | 41 ~ 104 °F (5~40 °C), 20 ~ 90% RH |
Rail kit | DW-VP16RE - 19" rackmount ears |
Recorder Dimensions (H X W X D) | 17.32” x 15.66” x 2.79” (440 × 397.8 ×71 mm) |
Serial ports | RS485, ONVIF |
Total PoE Power Budget | 150W |
USB interface | Yes |
Warranty | 5 Year Limited Warranty |
Model # | Supported Cameras | Storage Size |
DW-VP128P | Up tp 12 IP cameras | No local storage |
DW-VP123T8P | Up to 12 IP cameras | 3TB |
DW-VP124T8P | Up to 12 IP cameras | 4TB |
DW-VP126T8P | Up to 12 IP cameras | 6TB |
DW-VP1216T8P | Up to 12 IP cameras | 16TB |
DW-VP1218T8P | Up to 12 IP cameras | 18TB |
DW-VP1224T8P | Up to 12 IP cameras | 24TB |
DW-VP1232T8P | Up to 12 IP cameras | 32TB |
