DWC-B6883WTIRW

Star-Light Plus 4K UHDoC bullet camera with a vari-focal lens and IR
Features
  • Universal HD over Coax® technology with HD-Analog, HD-TVI, HD-CVI and all legacy analog signal support
  • Star-Light Plus™ color in near-total darkness technology
  • 1/1.8" image sensor
  • 4K at 15fps, 4MP or 2.1MP/1080p at real-time 30fps
  • 3.6 ~ 10mm vari-focal motorized zoom p-iris lens with auto-focus
  • True wide dynamic range (WDR)
  • OSD control via coaxial (UTC)
  • 150' Smart IR™ with intelligent camera sync.
  • Smart DNR™ 3D digital noise reduction
  • True day/night mechanical IR cut filter
  • De-Fog™ extreme weather image compensation
  • Auto-sensing 24VAC/12VDC with line lock
  • Easy icon-driven OSD menu with a built-in joystick
  • Programmable privacy zones
  • Auto gain control (AGC)
  • Backlight compensation (BLC)
  • Auto white balance (AWB)
  • Show More

Learn about how DW
solutions can work for you

View All Markets

Megapixel resolution

DW’s technology delivers crystal-clear images in resolutions up to 4K over coaxial infrastructure. Higher resolution delivers forensic details when zooming into the camera’s field of view.

Star-Light Plus™ color in darkness technology

Star-Light Plus™ color in near-total darkness technology provides crisp, clear images in the absence of ambient light.

Universal HD over Coax® Technology

Universal HD over Coax® Complete Solutions are the best way to upgrade an existing analog system to high-definition. Universal HD over Coax® cameras and recorders can transmit HD-Analog, HD-TVI, HD-CVI signals up to 4K, and analog signals to 960H.

True Wide Dynamic Range (WDR)

Cameras with True Wide Dynamic Range (WDR) technology have advanced sensors that can process a wider range of lighting, dark and bright in the same image.

Specifications

Active Pixels 3864 (H) x 2176 (V)
Frequency 50Hz, 60Hz
Image sensor 4K 1/1.8" CMOS sensor
Maximum resolution 2.1MP/1080p, 4K, 4K at 15fps, 4MP
Minimum Scene Illumination in color 0.0 lux (B/W), 0.09 lux (color)
Scanning System Progressive scan
Signal technology CVBS up to 960H, HD-Analog, HD-CVI, HD-TVI, Universal HD over Coax® technology
Test Video Output CVBS video output for testing
Lens
Advanced Lens Features Auto focus, Motorized zoom, P-iris
Focal Length 3.6mm ~ 10mm
Horizontal Field of View (HFOV) 98.4° ~ 45.7°
IR Distance 120' range Smart IR™
Lens Type Vari-focal Lens
Vertical Field of View (VFOV) 54.6° ~ 25.9°
Operational
3D digital noise reduction Smart DNR™ 3D Digital Noise Reduction
Auto gain control Auto
Backlight compensation (BLC) Yes
Camera Control UTC
Day and night Auto day/night, Day (color), Night (B/W)
De-fog Yes
DRC Yes
Gamma 0.45
Mirror/flip Yes
Motion Detection Yes
Privacy Zones 24 programmable provacy zones
Sharpness Yes
Shutter Mode Auto, Manual
Shutter Speed 1/30 ~ 1/30000
Star-Light (sense up) Disabled at 4K, Off, x2-x32
White Balance Yes
Wide Dynamic Range (WDR) True WDR 120dB
Environmental
Compliance CE  FCC  NDAA Compliance
Environmental Operating Humidity 10-90% (non-condensing)
Environmental Operating Temperature -4°F ~ 122°F (-20°C ~ 50°C)
Mounting Accessories (Required/Optional) Optional. Sold separately
Mechanical
Camera Dimensions (H X W X D) *Dimensions based on the position of the sun shield cover, 9.92" x 3.8" (252 x 96.7 mm)
Camera Weight 1.76 lbs (0.8kg)
Housing Bullet
Housing Color White
IP rating Weather Resistant (IP66)
Materials Aluminum die-casting
Electrical
American wire gauge (AWG) Cable type #18
Power Consumption AC24V(LED on): 7.81W , 325.4mA, AC24V(no LED): 4.95W, 206.2mA, DC12V (LED on): 8.34W, 692mA, DC12V (no LED): 5.49W, 457mA
Power Requirements 24 V AC
General
Warranty 5 Year Warranty

Accessories

DWC-V1CNMW
Corner and pole mount bracket - White
Learn more
DWC-BLJUNC-W
Junction box for white bullet cameras - white
Learn more
DWC-PMB-WLW
Pole mount bracket - white
Learn more

Documents

Title Type
DWC-B6883WTIRW datasheet - French
pdf Download
DWC-B6883WTIRW datasheet - Spanish
pdf Download
DWC-B6883WTIRW datasheet
pdf Download
DWC-B6883WTIRW quick setup guide
pdf Download
DW Accessories Chart
pdf Download
DWC-B6883WTIR AE specifications
docx Download
DWC-B6883WTIR CAD drawing
dwg Download
DWC-B6883WTIR_W user manual
pdf Download
Star-Light Plus brochure
pdf Download
