DWC-B7553WTIRW

Star-Light Plus 5MP UHDoC bullet camera with a fixed lens and IR

Features
  • Universal HD over Coax® technology with HD-Analog, HD-TVI and HD-CVI signal support
  • Star-Light Plus™ color in near-total darkness technology
  • 1/2.8" image sensor
  • 5MP at 20fps, 4MP at real-time 30fps
  • 4.0mm fixed lens
  • True wide dynamic range (WDR)
  • OSD control via coaxial (UTC)
  • 70' Smart IR™ with intelligent camera sync.
  • Smart DNR™ 3D digital noise reduction
  • True day/night mechanical IR cut filter
  • De-Fog™ extreme weather image compensation
  • Easy icon-driven OSD menu with built-in joystick
  • Programmable privacy zones
  • Auto gain control (AGC)
  • Backlight compensation (BLC)
  • Auto white balance (AWB)
  • UL listed
  • Show More

Megapixel resolution

DW’s technology delivers crystal-clear images in resolutions up to 5MP over coaxial infrastructure. Higher resolution delivers forensic details when zooming into the camera’s field of view.

Star-Light Plus™ color in darkness technology

Star-Light Plus™ color in near-total darkness technology provides crisp, clear images in the absence of ambient light.

Universal HD over Coax® Technology

Universal HD over Coax® Complete Solutions are the best way to upgrade an existing analog system to high-definition. Universal HD over Coax® cameras and recorders can transmit HD-Analog, HD-TVI, HD-CVI signals up to 4K, and analog signals to 960H.

Specifications

Active Pixels 2608 (H) x 1960 (V)
Frequency 60Hz, 50Hz
Image sensor 5MP 1/2.8" CMOS sensor
Maximum resolution 5MP, HD-Analog and HD-TVI: 5MP/1944p @ 20fps and 12.5fps, HD-Analog, HD-TVI and HD-CVI: 4MP/1440p @ 30fps, HD-Analog, HD-TVI and HD-CVI: 2.1MP/1080p @ 30fp, HD-Analog, HD-TVI and HD-CVI: 720p @ 30fp, Analog CVBS: Up to 960H @ 30fps
Minimum Scene Illumination in color 0.16 lux (color), 0.0 lux (B/W)
Scanning System Progressive scan
Signal technology Universal HD over Coax® technology, CVBS up to 960H, HD-Analog, HD-CVI, HD-TVI
Lens
Focal Length 4.0mm
Horizontal Field of View (HFOV) 82°
IR Distance 70' range Smart IR™
Lens Type Fixed Lens
Operational
Auto gain control Auto
Backlight compensation (BLC) Yes
Camera Control Pelco C, UTC
Day and night Auto day/night, Day (color), Night (B/W)
De-fog Yes
Gamma 0.45
Mirror/flip Yes
Motion Detection Yes
Operational features Star-Light Plus
Privacy Zones 24 programmable provacy zones
Sharpness Yes
Shutter Mode Auto
Shutter Speed 1/30 ~ 1/30000
Star-Light (sense up) Off, x2-x32
White Balance Yes
Wide Dynamic Range (WDR) True WDR 120dB
Environmental
Compliance NDAA Compliance, CF, FCC, RoHS
Environmental Operating Humidity 10-90% (non-condensing)
Environmental Operating Temperature -4°F ~ 122°F (-20°C ~ 50°C)
Mechanical
Dimensions 6.41" x 2.65" (163 x 67.5 mm)
Housing Bullet
IP rating Weather Resistant (IP66)
Materials Aluminum die-casting
Weight 1.10 lbs (0.5kg)
Electrical
Power Consumption DC12V (no LED): 2.0W, 176mA, DC12V (LED on): 6.12W, 510mA
Power Requirements 12 V DC
General
Warranty 5 Year Warranty

Accessories

DWC-B7JUNCW
Junction box for mini bullet cameras
Learn more
DWC-V1CNMW
Corner and pole mount bracket
Learn more
