DWC-PVF5M1TIRC2, DWC-PVF5M1TIRC1, DWC-PVF5M1TIRC6

MEGApix CaaS 5MP vandal fisheye IP camera with fisheye lens and IR
Find a Reseller Request a Demo Contact Us FAQs
NDAA
Features
  • All-in-one cameras, no server required
  • 5MP 1/1.8" image sensor at real-time 30fps
  • 1.5mm fisheye lens
  • Built-in 256/128/64GB storage options for up to 30 days retained video*
  • Support 360° hemispheric fisheye view and 360°, 180° and 90° panoramic views
  • Edge-to-edge image clarity
  • Easily to deploy with pre-loaded DW Spectrum® IPVMS for out-of-the-box operation
  • 24/7 access to live and recorded video feed
  • Automatic installation and licensing with first power on
  • Connect up to 30 MEGApix® CaaS™ edge cameras
  • Dual recording option with Blackjack® NAS appliance
  • Dual codecs (H.264, MJPEG) with simultaneous dual-stream
  • 55’ Smart IR™ with intelligent camera sync
  • Smart DNR™ 3D digital noise reduction
  • True day/night with mechanical IR cut filter
  • Programmable privacy zones
  • Auto gain control (AGC)
    • Show More

All-in-one cameras that do not require NVR’s, DVR’s or on-premise servers

MEGApix® CaaS™ cameras act as an all-in-one solution, handling recording, notifications, management and monitoring all accessed remotely, with no need for a dedicated server or remote recorder.

Camera as a system

The CaaS™ solution supports multiple cameras in the same network, and unlimited systems all accessible and manageable via DW Spectrum® client, app and DW Cloud™.

360° hemispheric and panoramic fisheye views at real-time 30fps

360° fisheye view IP cameras MEGApix® Pano™ 360° view fisheye cameras with IR monitor an entire room with a single camera, providing the ultimate ROI.

Ideal complete DW Spectrum® solution for small scale applications

The MEGApix® CaaS™, combined with Blackjack® NAS desktop products can deliver a complete DW Spectrum® network solution.

Specifications

Image sensor 4MP 1/3" CMOS sensor
Maximum resolution 5MP
Minimum Scene Illumination in color 0.39 lux (color), 0.0 lux (B/W)
Signal technology HD-TVI
Test Video Output Local video output CVBS 1.0V p-p (75Ω), 4:3 aspect ratio
Total Pixels 3096 (H) X 2080 (V)
Stream speed
Local server recording 64GB local memory for recording, 128GB local memory for recording, 256GB local memory for recording
Max. number of CaaS™ cameras in the same network/system Up to 30 MEGApix® CaaS™ cameras in the same network/system
Number of DW Spectrum® CaaS™ licenses included 1 DW Spectrum® CaaS™ license included
Lens
Focal Length 1.55mm
Horizontal Field of View (HFOV) 360°
IR Distance 55" range Smart IR™
Lens Type Fixed Lens
Operational
3D digital noise reduction 3D DNR
Auto gain control Auto
Day and night Auto day/nighy, Day (color), Night (B/W)
Mirror/flip Yes
Motion Detection Yes
Operational features True D/N
Operational Notifications Email, FTP server, Alarm output activation
Privacy Zones 4 programmable privacy masks
Sharpness Yes
Shutter Mode Auto, Manual, Slow Shutter, Anti-Flicker
Shutter Speed 1/30 ~ 1/32000
Slow Shutter Speed Off, x5, x7.5, x10
White Balance Yes
Network
Bitrate Control Multi-streaming CBR/VBR at H.264 (controllable frame rate and bandwidth)
IP IPv4
LAN RJ45 (10/100Base-T)
Network resolution 2592 X 1944, 640X480, 320X240
Network Web Viewer Windows® OS, Mac® OS, Linux® OS, Internet Explorer® browser, Google Chrome® browser, Mozilla Firefox® browser, Safari® browser
Protocol DDNS, DHCP, DNS, FTP, HTTP, HTTPs, ICMP, NTP, ONVIF, RTP (UDP/TCP), RTSP, SMTP, SNMPv1/v2/v3 (MIB-2), SSL, TCP/IP, UDP, Zeroconf (AutoIP)
Security HTTPS (TLS), IP filtering, 802.1x, Digest authemtication (ID/PW)
Stream Speed Up to 30fps at all resolutions
Video Bitrate 100Kbps~10Mbps, multi-rate for preview and recording
Video Compression Type H.264, MJPEG
Video Management Software DW Spectrum® IPVMS
Environmental
Compliance NDAA Compliance, UL Listing  CF, FCC, RoHS, ONVIF
Environmental Operating Humidity 0-90% RH (non–condensing)
Environmental Operating Temperature -4°F ~ 122°F (-20°C ~ 50°C)
Mechanical
Dimensions 4.66" x 3.58" (118.6 x 91 mm), 4.92" x 1.88” (125 x 48 mm), 4.92" x 2.9" (125 x 74.3 mm)
Housing Fisheye
IP rating Weather Resistant (IP66)
Materials Aluminum die-casting
Weight 1.10 lbs (0.5kg)
General
Power Consumption DC12V: max 6.5W, 541.6mA, PoE: max 3.6W
Power Requirements 12 V DC, PoE, IEEE 802.3af Class 3, (Adapter not included)
Warranty 5 Year Warranty

Part Numbers

Model #

Storage size

DWC-PVF5M1TIRC2
256GB
DWC-PVF5M1TIRC1
128GB
DWC-PVF5M1TIRC664GB

Accessories

DWC-VFZCM
Ceiling mount bracket for vandal dome and fishey cameras
Learn more
DWC-GPLT
Converter plate for electronic gang box
Learn more
DWC-V1CNM
Corner and pole mount bracket
Learn more
DWC-VFZJUNC
Junction box for vandal dome and fisheye cameras
Learn more
DWC-VFZWM
Wall mount bracket for selected vandal dome and turret cameras
Learn more

Videos

May 1, 2020 Customer Webinar: MEGApix CaaS All-in-One-Cameras and External Storage
August 7, 2020 Customer Webinar Recording: MEGApix® Fisheye Camera Setup Tips

Videos

May 1, 2020 Customer Webinar: MEGApix CaaS All-in-One-Cameras and External Storage
August 7, 2020 Customer Webinar Recording: MEGApix® Fisheye Camera Setup Tips

Documents

Title Type
Camera part numbering system
pdf Download
DW Accessories Chart
xlsx Download
DWC-PVF5M1TIRC AE Specifications
doc Download
DWC-PVF5M1TIRC CAD drawings
dwg Download
DWC-PVF5M1TIRC UL certificate
pdf Download
DWC-PVF5MTIRC data sheet
pdf Download
DWC-PVF5MTIRC data sheet - French
pdf Download
DWC-PVF5MTIRC data sheet - Spanish
pdf Download
DWC-PVF5MTIRC quick start guide
pdf Download
DWC-PVF5MTIRC user manual
pdf Download
MEGApix CaaS brochure
pdf Download
MEGApix CaaS solutions brief
pdf Download
MEGApix Single-Sensor Brochure
pdf Download
MEGApix® CaaS™ DW Spectrum® quick start guide
pdf Download
