DWC-MVA2WiAT
DWC-MPVA2WiAT

MEGApix 2.1MP/1080p vandal ball turret IP camera with a vari-focal lens and IR
Features
  • 2.1MP/1080P sensor at real-time 30fps
  • Star-Light Plus™ color in near-total darkness technology
  • Intelligent Video Analytics (IVA) with extended features (IVA+)
  • Seamless integration and control of IVA rules with DW Spectrum® IPVMS
  • Reduce false alarms
  • Increase your recording storage with logic rules and smart recording
  • Vari-focal p-iris lens with motorized zoom and autofocus for complete remote lens control and focused image any time
  • True Wide Dynamic Range (WDR) for clear images in challenging light
  • Simultaneous streaming and multiple codec options for smart bandwidth management
  • 100' Smart IR™ with intelligent camera sync for clear B/W images with no need for external light
  • Smart DNR™ 3D digital noise reduction reduces noise and ghosting for motion in low-light environments.
  • Privacy zones cover sensitive areas in the camera's field of view.
  • Web server built-in for easy camera management from any browser
  • PoE and DC12V for single cable simplified installation
  • NDAA compliant for federal and government projects
  • IP67- and IK10-rated camera housing built to last
  • 5 year warranty

Vandal turret housing

The vandal turret cameras have a unique dome-free design that allows for a true 90° tilting angle with endless 360° panning and rotation.

Star-Light Plus™ color in darkness technology

Star-Light Plus™ color in near-total darkness technology provides crisp, clear images in the absence of ambient light.

IVA Analytics

MEGApix IVA cameras include a base package of Intelligent Video Analytics detection capabilities already activated on the camera and ready for deployment.

Learn More.

IVA+ Analytics

The MEGApix IVA+ package offers advanced rules to the IVA Video Content Analysis detection capabilities.

Learn More.

True Wide Dynamic Range (WDR)

Cameras with True Wide Dynamic Range (WDR) technology have advanced sensors that can process a wider range of lighting, dark and bright in the same image.

Specifications

Image sensor 2.1MP/1080p 1/2.8" CMOS sensor
Maximum resolution 2.1MP/1080p
Minimum Scene Illumination in color 0.0 lux (B/W), 0.043 lux (color)
Test Video Output Local video output CVBS 1.0V p-p (75Ω), 4:3 aspect ratio
Total Pixels 1945 (H) X 1109 (V)
Lens
Advanced Lens Features Auto focus, Motorized zoom, P-iris
Horizontal Field of View (HFOV) 93.6° ~ 34.1°
IR Distance 100' range Smart IR™
Lens Type Vari-focal Lens
Vertical Field of View (VFOV) 19.2° ~ 51.8°
Intelligent Video Analytics
IVA license Intrusion, line crossing, counting line, loitering, enter, exit, tamper
IVA+ license Logical rules, object removed, tailgating, direction, stopped, appear, disappear, object left
Operational
3D digital noise reduction Smart DNR™ 3D Digital Noise Reduction
Auto gain control Auto
Backlight compensation (BLC) Yes
Day and night Auto day/night, Day (color), Night (B/W)
De-fog Yes
Memory slot Micro SD/SDHC/SDXC class 10 card (card not included), Up to 1TB micro SD / FAT32
Mirror/flip Yes
Motion Detection Yes
Operational Notifications Alarm output activation, Email, SD card recording
Privacy Zones 16 programmable privacy masks
Shutter Mode Auto, Manual, Slow Shutter
Shutter Speed 8 ~ 1/50000
Slow Shutter Speed Off, x15, x2, x3, x4, x5, x6, x7.5
White Balance Yes
Wide Dynamic Range (WDR) True WDR 120dB
Network
Bitrate Control Multi-streaming CBR/VBR at H.264 (controllable frame rate and bandwidth)
IP IPv4
Network resolution H.264: QFHD, 2.1MP/1080p, 720p, VGA, D1, CIF, H.265: QFHD, 2.1MP/1080p, 720p, VGA, D1, CIF, MJPEG: 1280x1024, 800x600, 480x360, 320x240, MJPEG: CIF
Network Web Viewer Google Chrome® browser, Linux® OS, Mac® OS, Microsoft Edge® browser, Mozilla Firefox® browser, Safari® browser, Windows® OS
Protocol Bonjour, DDNS, DHCP, DNS, Genetec Protocol, HTTP, HTTPs, IGMP, NTP, RTP, RTP (UDP/TCP), RTSP, SNMP, SNMPv1/v2/v3 (MIB-2), TCP, Telnet, UPnP, Zeroconf (AutoIP)
Security 802.1x, HTTPS (TLS), MAC filtering, Multi-user authority
Stream Speed Up to 30fps at all resolutions
Streaming Capability Dual-stream at different rates and resolutions
Video Bitrate 32Kbps~20Mbps
Video Compression Type H.264, H.265, MJPEG
Video Management Software DW Spectrum® IPVMS, ExacqVision Technologies, Milestone Systems
Environmental
Compliance CE  FCC  NDAA Compliance  ONVIF  UL Listing
Environmental Operating Humidity 10-90% (non-condensing)
Environmental Operating Temperature -4°F ~ 122°F (-20°C ~ 50°C)
Mounting Accessories (Required/Optional) Optional. Sold separately
Mechanical
Camera Dimensions (H X W X D) 4.92" x 4.4" (125 x 112mm)
Camera Weight 1.83 lbs (0.83kg)
Housing Vandal ball turret, Turret
Housing Color White
IK rating IK10 Rated
IP rating Weather Resistant (IP67)
Materials Aluminum die-casting
Electrical
American wire gauge (AWG) Cable type #18
Power Consumption DC12V: max 6.4W, 533.3mA, PoE: max 7.6W
Power Requirements Adapter not included, PoE
General
Warranty 5 Year Warranty

Part Numbers

Part Number Description
DWC-MVA2WiAT preloaded with IVA.
DWC-MPVA2WiAT preloaded with IVA+.

Accessories

DWC-VACM
Ceiling mount bracket for vandal ball turret cameras - White
Learn more
DWC-GPLT-W
Converter plate for electronic gang box - white
Learn more
DWC-VAJUNC
Junction box for vandal ball turret cameras - White
Learn more
DWC-WMJUNCW
Junction box for wall mounts and dual-sensor IP cameras - white
Learn more
DWC-PMB-WLW
Pole mount bracket - white
Learn more
DWC-VAWM
Wall mount bracket for vandal ball cameras - White
Learn more

Documents

Title Type
Camera part numbering system
pdf Download
DW Accessories Chart
pdf Download
DWC-M(P)VA series quick setup guide
pdf Download
DWC-MPVA2WiAT CAD drawing
dwg Download
MEGApix IVA brochure
pdf Download
MEGApix IVA user manual - rules and analytics
pdf Download
DWC-M(P)VA2WiAT series user manual
pdf Download
DWC-M(P)VA2WiAT datasheet
pdf Download
DWC-MVA2WiAT AE specifications
doc Download
DWC-MVA2WiAT CAD drawing
dwg Download

Software

Title Type Release Notes Version Update Date Compatibility Size
IVA and IVA+ plugin v1.0.113 zip v1.0.113 03/20/2024 14.40 MB Download
DW IP Finder v4.4.22 for Linux OS run v4.4.22 01/18/2024 46.00 MB Download
DW IP Finder v4.4.22 for Windows OS exe v4.4.22 01/18/2024 27.76 MB Download
DW Spectrum Linux plug-in v2.3.40 for MEGApix IVA and Ai IP cameras gz 01/15/2024 0.43 MB Download
DW Spectrum Windows 64bit exe plug-in v2.3.40 for MEGApix IVA and Ai IP cameras zip 01/15/2024 0.78 MB Download
DW Spectrum Windows 64bit plug-in v2.3.40 for MEGApix IVA and Ai IP cameras zip 01/15/2024 0.56 MB Download
MEGApix® Star-Light Plus™ 2.1MP/1080p firmware vA7.2.3_20230823 img vA7.2.3_20230823 09/18/2023 63.15 MB Download
