Home IP Cameras DWC-PVX20WATW, DWC-PPVX20WATW

DWC-PVX20WATW
DWC-PPVX20WATW

MEGApix Flex 20MP multi-sensor vandal dome IP camera with vari-focal lenses
Find a Reseller Request a Demo Contact Us FAQs
Features
  • 4x 5MP sensors (20MP) at real-time 30fps
  • Star-Light Plus™ color in near-total darkness technology
  • Intelligent Video Analytics (IVA) with extended features (IVA+)
  • Seamless integration and control of IVA rules with DW Spectrum® IPVMS
  • Reduce false alarms
  • Increase your recording storage with logic rules and smart recording
  • 4x vari-focal p-iris lens with motorized zoom and autofocus for complete remote lens control and focused image any time
  • 3-axis gimbal for wide range lens positioning
  • 360° and 180° flexible panoramic view IP camera
  • Four cameras in one installation
  • Flexible sensor positioning on a magnetic base
  • True Wide Dynamic Range (WDR) for clear images in challenging light
  • Simultaneous streaming and multiple codec options for smart bandwidth management
  • Smart DNR™ 3D digital noise reduction reduces noise and ghosting for motion in low-light environments.
  • Two-way audio for direct communication between the monitoring station and the camera's location
  • Local SD card slot for local recording in case of network loss
  • Alarm sensor input and relay output for access control integration
    • Show More

Learn about how DW
solutions can work for you

View All Markets

Versatile installation

A single Flex™ camera can replace multiple single-sensor cameras with great ROI. With a variety of lens arrangements and positioning, the camera can enhance any application and cover any area needed with no blind spots.

Magnetic track flexibility

The camera's unique magnetic track allows four individual lens modules to be placed in almost any possible configuration. A fifth, vertical, top view position in the center of the camera offers complete coverage and field of view control.

4x vari-focal lenses with motorized zoom and auto-focus

Adjust the camera’s four (4) individual vari-focal lens modules to achieve the ideal field of view based on your unique needs.

Easy camera installation

The camera includes a simple double-lock mechanizsm between the camera and mounting accessory, making installation quicker, simpler and faster.

Wide tilting angle

Each lens module has a total tilt angle of up to 80°, thanks to the modules' aspherical hemispheric surface. This reduces blind spots in the camera's foreground.

Star-Light Plus™ color in darkness technology

Star-Light Plus™ color in near-total darkness technology provides crisp, clear images in the absence of ambient light.

IVA Analytics

MEGApix IVA cameras include a base package of Intelligent Video Analytics detection capabilities already activated on the camera and ready for deployment.

Learn More.

IVA+ Analytics

The MEGApix IVA+ package offers advanced rules to the IVA Video Content Analysis detection capabilities.

Learn More.

Specifications

Image sensor 5MP 1/2.8" CMOS sensor (x4)
Maximum resolution 20MP
Minimum Scene Illumination in color 0.05 lux (color), 0.1 lux (B/W)
Test Video Output Local video output CVBS 1.0V p-p (75Ω), 4:3 aspect ratio
Total Pixels 2592 (H) × 1944 (V) (x4)
Lens
Focal Length 2.8mm ~ 8.0mm (x4)
Horizontal Field of View (HFOV) 4x 51° ~ 93°
Illumination Distance NA
Lens Type Vari-focal Lens
Vertical Field of View (VFOV) 39°~68° (x4)
I/O
Audio compression G.711
I/O Alarm in/out 1 input, 1 output
I/O Audio in/out *Cameras provide a line level audio. The use of amplified microphones and speakers is recommended., 1 input (1.0Vms, 3K ohm), 1 output
Intelligent Video Analytics
IVA license Intrusion, line crossing, counting line, loitering, enter, exit, tamper (DWC-PVX20WATW)
IVA+ license Logical rules, object removed, tailgating, direction, stopped, appear, disappear, object left (DWC-PPVX20WATW)
Operational
3D digital noise reduction Smart DNR™ 3D Digital Noise Reduction
Auto gain control Auto
Day and night Auto day/night, Day (color), Night (B/W)
De-fog Yes
Memory slot 4x Micro SD/SDHC/SDXC class 10 cards (cards not included), Up to 1TB micro SD / FAT32
Mirror/flip Yes
Motion Detection Yes
Operational Notifications Alarm output activation, Email, FTP server, SD card recording
Privacy Zones 16 programmable privacy masks
Sharpness Yes
Shutter Mode Anti-Flicker, Auto, Manual, Slow Shutter
Shutter Speed 1/15 ~ 1/32000
Slow Shutter Speed Off, x10, x2, x3, x5, x6, x7.5
White Balance Yes
Wide Dynamic Range (WDR) True WDR 120dB
Network
Bitrate Control Multi-streaming CBR/VBR at H.264, H.265 (controllable frame rate and bandwidth)
IP IPv4
LAN 1000Base-T (1Gbps)
Network resolution 4. H.264: 2592x1944 2560x1440 1920x1080 704x576 704x480 640x480 640x360 352x288 352x240, 4x MJPEG: 1920x1080, 1280x720, 800x600, 768x432, 704x576, 704x480, 640x480, 640x360, 352x288, 352x240
Network Web Viewer Google Chrome® browser, Linux® OS, Mac® OS, Microsoft Edge® browser, Mozilla Firefox® browser, Safari® browser, Windows® OS
Protocol DDNS, DHCP, DNS, FTP, HTTP, HTTPs, ICMP, NTP, RTP (UDP/TCP), RTSP, SMTP, SNMPv1/v2/v3 (MIB-2), SSL, TCP/IP, UDP, Zeroconf (AutoIP)
Security 802.1x, Digest authentication (ID/PW), HTTPS (TLS), IP filtering
Stream Speed Up to 30fps at all resolutions
Streaming Capability Dual-stream at different rates and resolutions
Video Bitrate 100Kbps~10Mbps, multi-rate for preview and recording
Video Compression Type H.264, H.265, MJPEG
Video Management Software DW Spectrum® IPVMS, ExacqVision Technologies, Milestone Systems
Environmental
Compliance CE  FCC  NDAA Compliance  UL Listing
Environmental Operating Humidity 10-90% (non-condensing)
Environmental Operating Temperature -4°F ~ 122°F (-20°C ~ 50°C)
Mounting Accessories (Required/Optional) Required. Sold separately
Mechanical
Camera Dimensions (H X W X D) 8.26" x 3.61" (210 x 91.8 mm)
Camera Weight 4.18 lbs (1.9kg)
Housing Panoramic, Vandal Dome
Housing Color White
IK rating IK10 Rated
IP rating Weather Resistant (IP67)
Materials Aluminum die-casting
Electrical
American wire gauge (AWG) Cable type #18
Power Consumption DC12V: max 28W, 2.33A, PoE: max 28W, 2.583A
Power Requirements High power PoE injector included, PoE
General
Warranty 5 Year Warranty

Part Numbers

Part Number Description
DWC-PVX20WATW Preloaded with IVA.
DWC-PPVX20WATW Preloaded with IVA+.

Accessories

DWC-PV20CMW
Ceiling mount bracket for muti-sensor vari-focal dome cameras - white
Learn more
DWC-V1CNMW
Corner and pole mount bracket - White
Learn more
DWC-PV20FMW
Flush mount for muti-sensor vari-focal dome cameras - white
Learn more
DWC-PV20HMW
Hanging mount for selected multi-sensor cameras for custom built arm mount - white
Learn more
DWC-PV20JUNCW
Junction box for muti-sensor vari-focal dome cameras - white
Learn more
DWC-PZPARAMW2
Parapet mount (requires DWC-PZADPW or DWC-PV20ADPW tilting adapter, sold separately) - white
Learn more
DWC-PV20ADPW
Parapet mount tilting adapter for DWC-PZPARAMW - white
Learn more
DWC-PMB-WLW
Pole mount bracket - white
Learn more
DWC-PV20WMW
Wall mount bracket for muti-sensor vari-focal dome cameras - white
Learn more
DWC-PZPARAMW
Parapet mount (requires DWC-PZADPW or DWC-PV20ADPW tilting adapter, sold separately) - white
Learn more

Documents

Title Type
DWC-P(P)VX20WATW AE Specifications
docx Download
DWC-P(P)VX20WATW CAD Drawing
dwg Download
DWC-P(P)VX20WATW datasheet
pdf Download
DWC-P(P)VX20WATW Quick Setup Guide
pdf Download
DWC-P(P)VX20WATW User Manual
pdf Download
DW Accessories Chart
pdf Download
MEGApix Pano solutions brief
pdf Download
MEGApix Flex Brochure
pdf Download
View All Documents

Software

Title Type Release Notes Version Update Date Compatibility Size
DW IP Finder v4.4.23 for Linux OS run v4.4.23 09/10/2024 46.11 MB Download
DW IP Finder v4.4.23 for Windows OS exe 07/01/2024 27.80 MB Download
IVA and IVA+ plugin v1.0.113 zip v1.0.113 03/20/2024 14.40 MB Download
DWC-P(P)VX20WATW firmware vS13.2.3_20230901 img vS13.2.3_20230901 09/18/2023 27.85 MB Download
IVA and IVA+ plugin v1.0.71 for DWC-P(P)VX20WATW enc - v1.0.71 01/13/2023 DWC-P(P)VX20WATW 14.22 MB Download
